10-Channel Classic Magnetic Hotplate Stirrer

10-Channel Classic Magnetic Hotplate Stirrer thumbnail-1
10-Channel Classic Magnetic Hotplate Stirrer photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
KINGDAK
Model Number:
MS-H-S10
Contact Supplier Request Quote Chat Now
Shanghai Kingdak Industries Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name KINGDAK
Model Number MS-H-S10

10-Channel Classic Magnetic Hotplate Stirrer



Features of MS-H-S10

-  Heating temperature up to 120°C

- High performance multi-position magnetic stirrer with uniform temperature distribution
- Individually controlled stirring for consistency with various samples
- Individually controlled stirring for consistency with various samples
- Electronic speed control motor provides constant speed
- DC brushless motor maintenance free and quiet running
- Stainless steel plate with silicone films, anti-slip and anti-corrosion


Specifications:

  MS-H-S10
Dimension of work plate [mm] 180×450
Work plate material Stainless steel with silicone Film
Motor type DC motor
Motor rating input [W] 12
Motor rating output [W] 4
Power [W] 490
Voltage [VAC] 200-240
Frequency [Hz] 50/60
Stirring positions 10
Max. stirring quantity[H2O], L 0.4 (each stirring position)
Max. magnetic bar(L x Ø) [mm] 40
Speed range [rpm] 0-1100
Speed display Scale
Heating output [W] 470
Heating temperature range [°C] RT-120
Safety temperature [°C] 140
Temperature display Scale
Protection class according to DIN EN60529 IP42
Dimension [W x D x H] mm 182×552×65
Weight [kg] 3.2
Permissible ambient temperature [°C] 5-40
Permissible relative humidity 80%



ordering info:

Cat No. P/N Descriptions Power supply
811321020000 MS-H-S10 10-Channel Classic Hotplate Magnetic Stirrer, stainless steel plate with silicone film, heating temperature up to 120°C USA plug,100V-120V/50Hz/60Hz
811321010000 Cn plug,200V-240V/50Hz/60Hz
811321030000 Euro plug,200V-240V/50Hz/60Hz
811321040000 UK plug,200V-240V/50Hz/60Hz
Accessories
18900006 MSBAR10 Stirrer bar(10mm x 6mm),1pc/pk
18900007 MSBAR15 Stirrer bar(15mm x 8mm),1pc/pk
18900008 MSBAR20 Stirrer bar(20mm x 8mm),1pc/pk
18900009 MSBAR25 Stirrer bar(25mm x 8mm),1pc/pk
12500005 MSBAR30 Stirrer bar(30mm x 6mm),1pc/pk
18900011 MSBAR40 Stirrer bar(40mm x 8mm),1pc/pk
18900015 MARRM Stirrer bar remover, length of 200mm, 1pc/pk


 10-Channel Classic Magnetic Hotplate Stirrer10-Channel Classic Magnetic Hotplate Stirrer10-Channel Classic Magnetic Hotplate Stirrer
