10-Channel Classic Magnetic Hotplate Stirrer
Negotiable
/ Set
1 Set(Min.Order)
- 200 Set / Sets per Month
- SHANGHAI
- Credit Card PayPal
You May Like
- Sand Water Filter/Water treatment plants
- Automatic Doypack Seal Machine (insert and sealing machine)
- Portable gas analyzer for detecting and measuring gas concentration K850 for power station
- Liquid level transmitter
- IPX3/IPX4 Hand-held Water Spray Nozzle Test Device IEC 60529
- IPX5,IPX6 Jet Nozzle of IEC 60529, Brass material
Product Details
Place of Origin: | Shanghai, China | Brand Name: | KINGDAK | Model Number: | MS-H-S10 |
Product Description
10-Channel Classic Magnetic Hotplate Stirrer
Features of MS-H-S10
- Heating temperature up to 120°C
- High performance multi-position magnetic stirrer with uniform temperature distribution
- Individually controlled stirring for consistency with various samples
- Individually controlled stirring for consistency with various samples
- Electronic speed control motor provides constant speed
- DC brushless motor maintenance free and quiet running
- Stainless steel plate with silicone films, anti-slip and anti-corrosion
- Individually controlled stirring for consistency with various samples
- Individually controlled stirring for consistency with various samples
- Electronic speed control motor provides constant speed
- DC brushless motor maintenance free and quiet running
- Stainless steel plate with silicone films, anti-slip and anti-corrosion
Specifications:
MS-H-S10 | |
Dimension of work plate [mm] | 180×450 |
Work plate material | Stainless steel with silicone Film |
Motor type | DC motor |
Motor rating input [W] | 12 |
Motor rating output [W] | 4 |
Power [W] | 490 |
Voltage [VAC] | 200-240 |
Frequency [Hz] | 50/60 |
Stirring positions | 10 |
Max. stirring quantity[H2O], L | 0.4 (each stirring position) |
Max. magnetic bar(L x Ø) [mm] | 40 |
Speed range [rpm] | 0-1100 |
Speed display | Scale |
Heating output [W] | 470 |
Heating temperature range [°C] | RT-120 |
Safety temperature [°C] | 140 |
Temperature display | Scale |
Protection class according to DIN EN60529 | IP42 |
Dimension [W x D x H] mm | 182×552×65 |
Weight [kg] | 3.2 |
Permissible ambient temperature [°C] | 5-40 |
Permissible relative humidity | 80% |
ordering info:
Cat No. | P/N | Descriptions | Power supply |
811321020000 | MS-H-S10 | 10-Channel Classic Hotplate Magnetic Stirrer, stainless steel plate with silicone film, heating temperature up to 120°C | USA plug,100V-120V/50Hz/60Hz |
811321010000 | Cn plug,200V-240V/50Hz/60Hz | ||
811321030000 | Euro plug,200V-240V/50Hz/60Hz | ||
811321040000 | UK plug,200V-240V/50Hz/60Hz | ||
Accessories | |||
18900006 | MSBAR10 | Stirrer bar(10mm x 6mm),1pc/pk | |
18900007 | MSBAR15 | Stirrer bar(15mm x 8mm),1pc/pk | |
18900008 | MSBAR20 | Stirrer bar(20mm x 8mm),1pc/pk | |
18900009 | MSBAR25 | Stirrer bar(25mm x 8mm),1pc/pk | |
12500005 | MSBAR30 | Stirrer bar(30mm x 6mm),1pc/pk | |
18900011 | MSBAR40 | Stirrer bar(40mm x 8mm),1pc/pk | |
18900015 | MARRM | Stirrer bar remover, length of 200mm, 1pc/pk |
