Portable laser dust particle counter/Type Laser Dust Particle Counter

Parameter/model

KD09-6 Serial Laser Particle Counter (LCD)

Size of appearance

230*280*126mm³

Ways of display

LCD

Quality

4.5kg

Maximum power consumption

40w

Power supply

AC 220V±10%,50HZ

Particle size passage

0.3,0.5,1,2,3,5 10(µm)

Six categories of size are displayed at the same time

the particle concentration is displayed directly (unit: grain/2.83L, grain/m³)

Sampling flow

2.83L/min

Inspection period

1min,2min ,3min ,10min

Self-clean time

≤20 min

Print

Built-in printer

Alarming

Class100, 1000, 10000

Environment condition for use

Temperature: 10^oc-30^o c, humidity:20%-70%,gas pressure:86kPa-106kPa

Maximum sampling concentration allowed

35000 grains/L (the particle diameter shall be no larger than 0.5µm) and the sampling air shall not include the erosive acid and aklaili gases.

Sustainable working period

8 hours

Light source and service life

Semiconductor laser, with the service life longer than 30000 hours

Data storage

240 groups

Optional pieces

Supplementary measuring vehicle (bring the chargeable power supply, it could be used continuously for 6 hours)PC remote control card and special software

Fittings

Sampling bracket, 1 constant velocity sampler, 1 self-cleaner, 5 volumes of dustless printing paper, 1 dustless notebook
