Technical Parameter of laboratory XFD Single Flotation Cell
XFG flotation machine mainly for coal, electricity, mining, geology, chemistry, metallurgy, mining processing plant and laboratory scientific research institutions, mixing, separation, scrubbing, selected ore samples and so on, the aircraft flotation speed and other indicators of the election good, easy and accurate adjustment, operation reliable, low-grade ore to the ore and rare ore sample analysis, require a higher concentration than the selection of a small amount of mineral samples, The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Mineral Resources,in compliance with the Industrial standards
XFG the second generation of new products with variable frequency technology, digital display, adjust the precise, reliable operation and so on.
Model | Capa | Volume of tank | Impeller diamete | Impeller speed | Power | Weight |
0.2 mm | g | L | mm | r/min | w | kg |
XFG 5-35g | 5,15,25,35 | 20,60,100,140 | 20,26,30 | 1000-1850 | 60 | 15 |
XFG 50-100g | 50,100 | 200,400 | 36,48 | 1000-1800 | 60 | 16 |
XFG 250-500g | 250,500 | 1000,2000 | 60,64 | 1500,2000 | 250 | 25 |
XFG 1000g | 1000 | 4000 | 80 | 900-1500 | 250 | 27 |
