Help CenterHigh Qualit Lab Ball Mill /Laboratory Mineral Equipment
Related Products
-
Laboratory Planetary Ball Mill,small Test Grinding Mill,wet Ore Grinding Processing,dry Lab Ball Mill EquipmentUS$ 1,200 - 3,600MOQ: 1 Set -
Lab Grinding Mill,small Attritor ,laboratory Test Ball Mill,grate Grinder Equipment,energy Planetary Ball Milling MachineUS$ 2,100 - 68,000MOQ: 1 Set
-
Continuous Feeding Lab Disc Mill/small and Cheap Price Portable Lab Disc MillUS$ 800 - 2,000MOQ: 1 Set
-
Lab Disc Mill For Coal Milling Equipment/Lab Grinding MillUS$ 500 - 3,000MOQ: 1 Set
-
Mini Benchtop Experiment Ideal Sample Grinding Machine/ Lab Pigment Grinding Machine/Vertical Planetary Ball MillUS$ 10 - 50,000MOQ: 1 Set
Specifications
laboratory ball milleasy operate
for lab testing & small grinding ore
Planetary lab ball mill
laboratory XMQ Cone ball Mill
prodrct description
1.easy maintenance
2.even final particles
3.high crushing ratio
4.firm structure...
XMQ Series Cone Ball Mill is a lab.grind equipmet for wet fine grinding of ore.It is applied in labs for processing and fine grinding of artifical placer materials and ores in metallurgical,building material,chemical,light,coal,water conservancy,electric power,agricultural and geological industries.The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Mineral Resources,in compliance with the Industrial standards
The experiment of grinding equipment, grinding time can be arbitrarily set, but also can be used in dry, wet grinding, using frequency conversion technology, speed range is wide, abrasive, mixing and even everything easy installation without foundation treatment, low noise, no dust pollution, to facilitate the work of cleaning, polishing sealing performance is good, ordinary ore optional experimental study and manual re-sanding of ore used in the rod mill more appropriate. The grinding equipment, a large amount of feeding, discharging, cylinder power control, without manual, grinding time can be arbitrarily set
Technical Parameter
Model |
Uite |
XMQ150/50 |
XMQ240/90 |
XMQ350/160 |
Drum size |
mm |
150/50 |
240/90 |
350/160 |
Volume |
L |
1 |
6.25 |
21.58 |
Capacity |
g |
200 |
1000 |
4000 |
Feed size |
mm |
3 |
3 |
3 |
Rarticle size |
mm |
0.074 |
0.074 |
0.074 |
Drum speed |
r/min |
110-114 |
94-98 |
60-64 |
rower |
kw |
0.25 |
0.55 |
1.1 |
Overall dimensions |
mm |
915/530/1160 |
1050/640/1164 |
700/575/1190 |
Weighe |
kg |
91 |
170 |
300 |
