Specifications
1. Large capacity.2. Low consumption.3. Easy to operate.4. Easy to service.5. Long service life.6. Energy conservation
Belt conveyor, belt conveyer) say again sellotape conveyor, commonly known as the "belt conveyor". Now in addition to the rubber belt conveyor belt, and there are other materials of belt (such as PVC, PU, teflon, nylon tape, etc.). Belt conveyor by driving devices taut conveyor belt, the central structure and roller conveyor belt as of traction and bearing structure, so as to continuous transmission of material or broken into pieces scattered products.
Belt conveyor widely used in metallurgy, coal, transportation, water and electricity, chemical industry, building materials, power, light industry, food, port, shipping, and other departments, because it has large transportation amount, simple structure, easy maintenance, low cost, strong commonality, etc. Common belt conveyor is consisted by roller, roller and drive, braking, tensioner, redirection, loading or unloading cleaning devices
B Q V (m/s) | bandwidth(mm) | |||||
500 | 650 | 800 | 1000 | 1200 | 1400 | |
productivity(t/h) | ||||||
0.8 | 78 | 131 | — | — | — | — |
1.0 | 97 | 164 | 278 | 435 | 655 | 891 |
1.25 | 122 | 206 | 348 | 544 | 819 | 1115 |
1.6 | 156 | 264 | 445 | 696 | 1043 | 1427 |
2.0 | 191 | 323 | 546 | 835 | 1284 | 1748 |
2.5 | 232 | 391 | 661 | 1033 | 1553 | 2118 |
3.15 | — | — | 824 | 1233 | 1853 | 2528 |
4.0 | — | — | — | — | 2202 | 2996 |
