Home > Manufacturing & Processing Machinery > Mining Machinery > Mineral Separator > Lab Vertical Sand Pump
US$ 200 - 2,200
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, conveying equipment
Production Capacity:
20-30 L/min
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Other, conveying equipment
Production Capacity
20-30 L/min
Place of Origin
Jiangxi, China
Brand Name
oasis
Model Number
XBSL13(1/2)
Voltage
380 V
Power(W)
750
Dimension(L*W*H)
420/280/460
Weight
65 kg
Certification
ISO9001:2008
Warranty
One year
After-sales Service Provided
Overseas service center available
XBSL type vertical sand pump for conveying the pulp and tablets of mine laboratories can also be used in coal preparation plant transmission medium, aluminum easy to transport high-temperature crystallization, as well as cement plants are expected to transport materials. This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standards.
Model | Unit | XBSL13(1/2) | XBSL19(3/4) | XBSL25(1) | XBSL38(3/2) |
Outler diameter | mm | 13 | 19 | 25 | 38 |
Head | m | 5 | 6 | 9 | 12 |
Flow rate | L/min
| 20-30 | 55 | 110 | 250 |
Feed density | % | 30 | 30 | 30 | 30 |
Voltage | v | 380 | 380 | 380 | 380 |
power | kw | 0.75 | 1.1 | 1.5 | 3 |
Overall dimensions | mm | 420/280/460 | 480/350/550 | 680/500/640 | 690/480/680 |
Weight | kg | 65 | 110 | 157 | 200 |
