HF98V Auto Thermoforming & Vaccum Packing Machine

  Auto Thermoforming & Vaccum Packing Machine

HF-98V Auto Thermoforming & Vacuum Packing Machine series utilize tensility to thermoforming container by thermoplastic soft or hard film, and vacuum sealing after filling, vacuuming, sealing and cutting together to improve efficiency by low energy consumption.


Features:
1. Easy clean and sanitary by stainless steel construction.
2. BUSCH vacuum pump from Germany guarantee performance and durability.
3. Digital display PLC interface with touching panel from Japan for easy operation.

4. Various wrapper and specification choice with scope on the same machine.
5. Servo diver from Japan makes circulate placidly and accurately.
6. Versality in running many different formats and sizes on same machine only need to change mould.
7. Other gas mixer available based on vacuum to extend fresh time.

Technical Data:
Packing Capacity:                  2-4cycles/min
Bottom film thickness:          ≤0.8mm
Bottom film width:                  322, 422, 522mm
Top film width:                        285,385, 485mm
Max. forming area:                 ≤500x400mm
Max. forming depth:               80mm
Power Supply:                        3 PH/ AC380V/50HZ
Air Consumption:                   500-650L/min
Dimension(mm):                   4500x1000x1760( Lx W x H)
Weight:                                     pprox1300kg
Air Supply:                                ≥0.6Mpa
Loading Length:                     ≥1.5m
Power:                                      10kw

Optional Functions:
Printing Function: Printout single or multiple lines with production date, numbers of code and batch
Provide CIP washing system
Linear conveyor transport output automatically
