Home > Transportation > Forklifts & Parts > Forklift > 2.5 Ton Nissan Engine Gasoline/ Gas Forklift Truck

2.5 Ton Nissan Engine Gasoline/ Gas Forklift Truck

Name: 2.5 Ton Nissan Engine Gasoline/ Gas Forklift Truck
Brand: MACH
SKU: 141435128
Availability: InStock

Dalian Mach Co., Ltd.

2.5 Ton Nissan Engine Gasoline/ Gas Forklift Truck thumbnail-1

2.5 Ton Nissan Engine Gasoline/ Gas Forklift Truck photo-1

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Liaoning, China

Brand Name:

MACH

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian Port China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Liaoning, China

Brand Name MACH

Model Number CPYD25

Type Powered Pallet Truck

Power Souce Gasoline Engine

Rated Loading Capacity 2.5 tons

Max. Lifting Height 3 meter, 2 stage-mast

Min. Lifting Height .

Fork Length 1070mm

Fork Width .

Overall Dimensions .

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

2.5Ton Nissan Engine Gasoline/Gas Forklift Truck

2.5 ton Petrol/Gas Forklift Model: CPYD25

Rated capacity: 2.5 ton

Lift Height: 3 meters

With two stage mast

Engine: Nissan K25

Forks Length: 1070mm

Hydraulic Transmission

CE Certificate & ISO Certificate

Detailed Specification:

	1	MODEL				CPYD25FB
	2	RATED CAPACITY		Kg		2500
	3	LOAD CENTRE		mm		500
	4	LIFTING HEIGHT		mm	B	3000
BASED	5	MAX.HEIGHT(FORK CARRAGE)		mm	A	4053
	6	MAST HEIGHT		mm	C	2090
DATA	7	FREE LIFT HEIGHT		mm	E	145
	8	MAST INCLINATION(F/R)		o	Y	6
	9	FORK LENGTH		mm	J	1070x100x45
	10	SUSPENSION(F/R)		mm	U	475'5
	11	BRAKING DISTANCE(UNLOADED)		m	F	6
	12		LOADED	mm/s	K	550
	13	LIFTING SPEED	UNLOADED	mm/s	M	580
	14		LOADED	mm/s		600
	15	LOWERING SPEED	UNLOADED	mm/s		300
PERFORMANCE	16		LOADED	mm/s		18
	17	TRAVELLING SPEED	UNLOADED	mm/s		20
DATA	18	MIN.TURNING RADIUS(OUTSIDE)		mm	W	2245
	19	MIN.TURNING RADIUS(INSIDE)		mm	V	200
	20	MIN.WIDTH OF ANGLEAISLE		mm	X	1930
	21	MAX. GRADIENT		%		20
	22		FRONT	Kg		5527
	23	AXLELOAD(LOADED)	REAR	Kg		683
	24		FRONT	Kg		1670
	25	AXLELOAD(UNLOADED)	REAR	Kg		2040
	26	OVERALL LENGTH(DISCLUDE FORK)		mm	H	2538
	27	OVERALL WIDTH		mm	Q	1145
	28	OVERALL HEIGHT(OVERHEAD GUARD)		mm	P	2070
	29	WHEEL		mm	L	1600
SIZE	30		FRONT	mm	S	970
AND	31	TRACK	REAR	mm	T	980
WEIGHT	32	MINI.GROUND CLEARANCE		mm	G	115
	33	HEIGHT OF TRACTION COUPLER		mm	N	205
	34	HEIGHT FROM SEAT TO OVERHEAD GUARD		mm	O	1000
	35	SPACING(OUT-TO-OUT)		mm	R	250-983
	36	SERVICE WEIGHTS		Kg		3710
	37	MODEL				Nissan K25
ENGINE	38	POWER TYPE				Gasoline/ LPG
	39	GEAR SHIFT(F)				1-1power shift
TRANSMISSION	40	GEAR SHIFT(R)				2-2hand shift
	41	DRIVING BRAKE				hydraulic pedal
BRAKING TYPE	42	PARKING BRAKE				mechanical hand
	43	FRONT TYRE (PNEUMATIC)				7.00-12-12PR
		REAR TYRE (PNEUMATIC)				6.00-9-10PR
TYRE	44	PRESSURE		Mpa		0.7
	45	VOLTAGE		V		12
BATIERY	46	CAPACITY		AH		N100
TRANSMISSION TYPE						HYDRAULIC

About our company:

DALIAN MACH CO.,LTD specialize in manufacturing and exporting all kinds of machinery. Such as: Metal Processing Machine, Paper Processing Machine, Packaging Machine, Rubber Machine, Pharmaceutical Machine, Daily Product Making Machine, Forklift, etc. With more than twenty-year experience, Our professional team will provide best service for you.

We have a group of professional engineers in charge of technology, manufacturing, installing, testing. So we can guarantee that our machines will be runned on good performance based on high quality.

Our products have been exported to more than 60 countries. Such as: Canada, U.S.A, Italy, France, Guatemala, Brazil, Bolivia, Chile, Russia, Romania, Saudi Arabia, Syria, Jordan, U.A.E, Indonesia, Singapore, Thailand, India, Pakistan, South Africa, Egypt, Nigeria, Kenya, Ghana,etc.

We sincerely hope to establish long-term cooperative relationship with you and become a true partner who is always available when you need our service

...
