3.5 Tons Japan ISUZU Engine Diesel Forklift
- 50 Unit / Units per Month
- Dalian Port China
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Liaoning, China | Brand Name: | MACH |
Model Number: | CPCD35RB | Type: | Powered Pallet Truck | Power Souce: | Diesel Engine |
Rated Loading Capacity: | 3.5 tons | Max. Lifting Height: | 3 meter | Min. Lifting Height: | . |
Fork Length: | 1070mm | Fork Width: | . | Overall Dimensions: | . |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
3.5Tons Japan ISUZU Engine Diesel Forklift
Specification:
MODEL | CPCD35RB | ||||||
1 | RATED CAPACITY | Kg | 3500 | ||||
2 | LOAD CENTRE | mm | 500 | ||||
3 | MAST TYPE | CJ | |||||
PERFORMANCE | 4 | LIFTING HEIGHT | mm | B | 3000 | ||
DATA | 5 | MAX.HEIGHT(FORK LIFTED) | (FOKK LIFT) | mm | D | 4053 | |
6 | FREE LIFT HEIGHT | mm | E | 150 | |||
7 | MAST INCLINATION(F/R) | . | 6 | ||||
8 | FORK(LxWxT) | mm | 1070x50x122 | ||||
9 | TRAVELLING SPEED | LOADED | Km/h | 18 | |||
10 | UNLOANED | Km/h | 20 | ||||
11 | LIFTING SPEED | LOADED | mm/s | 400 | |||
PERFORMANCE | 12 | UNLOANED | mm/s | 430 | |||
13 | LOWERING SPEED | LOADED | mm/s | <600 | |||
DATA | 14 | UNLOANED | mm/s | ≥300 | |||
15 | MIN.TURNING RADIUS | mm | F | 2474 | |||
16 | MIN.WIDTH OF ANGLE AISLE | mm | G | 2065 | |||
17 | BRAKE DISTANCE | m | ≤6 | ||||
18 | MAX.GRADIENT | % | 15 | ||||
19 | OVERALL LENGTH(INCLUDE FORK) | mm | H | 3825 | |||
20 | OVERALL WIDTH | mm | I | 1225 | |||
21 | OVERALL HEIGHT(FORK ON GROUDN) | mm | C | 2255 | |||
22 | OVERHEAD GUARD(CABIN)HEIGHT | mm | J | 2160 | |||
SIZE | 23 | WHEEL BASE | mm | K | 1700 | ||
WEIGHT | 24 | TRACK | FRONT | mm | L | 1000 | |
25 | REAR | mm | M | 970 | |||
26 | MIN.GROUND CLEARANCE | mm | N | 149 | |||
27 | SERVICE WEIGHTS | Kg | 4700 | ||||
28 | GEAR SHIFT(F/R) | 2/2 hand operated | |||||
OPERATION | 29 | BRAKE DISTANCE | BRIVING BRAKE | Hydraulic pedal | |||
TYPE | 30 | PARKING BRAKE | MECHANICAL-HAND OPERATING | ||||
31 | POWER TYPE | DIESEL | |||||
32 | MODEL | 4JG2PE | |||||
33 | MANU FACTURER | ISUZU | |||||
34 | RATED OUTPUT | Kw/rpm | 44.9/2450 | ||||
ENGINE | 35 | MAX.TORQUE | Nm/rpm | 186.3/1600, | |||
36 | CYL.NO/DISPLACEMENT UNIT/L | n/L | 4/3.059, | ||||
37 | FUEL CONSUMPTION | g/Kw.h | 262 | ||||
38 | REVOLUTION UNLOAD(MIN./MAX.) | 700/2450 |
About our company:
DALIAN MACH CO.,LTD specialize in manufacturing and exporting all kinds of machinery. Such as: Metal Processing Machine, Paper Processing Machine, Packaging Machine, Rubber Machine, Pharmaceutical Machine, Daily Product Making Machine, Forklift, etc. With more than twenty-year experience, Our professional team will provide best service for you.
We have a group of professional engineers in charge of technology, manufacturing, installing, testing. So we can guarantee that our machines will be runned on good performance based on high quality.
Our products have been exported to more than 60 countries. Such as: Canada, U.S.A, Italy, France, Guatemala, Brazil, Bolivia, Chile, Russia, Romania, Saudi Arabia, Syria, Jordan, U.A.E, Indonesia, Singapore, Thailand, India, Pakistan, South Africa, Egypt, Nigeria, Kenya, Ghana,etc.
We sincerely hope to establish long-term cooperative relationship with you and become a true partner who is always available when you need our service.
...
