Shisha Charcoal Manufacturing Plant Hookah Charcoal Briquette Making Machine
Brief Introduction:
1. Our factory Gongyi Lantian Machanical Plant is a professional manufacturer of shisha charcoal machines.
2. We have hydraulic type and mechanical type shisha charcoal machine.
3. Our this shisha charcoal machine is a special machine that putting the small particles or powder materials into the molds and pressing them into the briquettes.
4. The outlet shapes can be round tablet, cubic, rhomboid, triangular, cylinder, scrotiform, cone, convexity, concavity and others with word, logo, pattern, and other special shapes.
5. The outlet shisha charcoal are good looking, smokeless, non toxic, long buning, high heat, easy light or normal light.
6. Our shisha charcoal machine, processing large kind of powder materials, can be used for coal and charcoal industry, pharmaceutical industry, food industry, chemical industry, metallurgical industry, building materials industry, refractory industry, and others.
Finished Shisha Charcoal Briquettes:
1. Size and shapes:
(1) Size: round: 20-45mm, square: 15-55mm
(2) Shape: round, square, restabgle, triangle, cylinder, diamound, cone, etc.
(3) The shape of briquettes can be customized.
2. Characteristics:
(1) The shisha charcoal briquettes use quick burning charcoal technology, can burn from the top to down.
(2) Firepower fierce, smokeless, tasteless, non-toxic, long burning time.
(3) Square shape shisha charcoal can burn for about 1-1.5 hours.
(4) Round tablet shisha charcoal can burn for about 40 minutes.
Mechanical type shisha charcoal machine:
Features:
1. Automatic feeding and discharging system.
2. Solid crank arms and strengthly pressing.
3. We can customize the different molds for making different shaped briquettes.
4. The mold can be easily changed and maintained.
5. Buffer device for mechanical pressure machine to avoide any damage of parts caused by overloading.
6. This shisha charcoal machine can manually working or automatic working.
Hydraulic shisha charcoal machine:
Features:
1. The hydrualic shisha charcoal machine is composed of main machine, hydraulic cylinder, conveyor and PLC cabinet.
2. The pressure of this machine is about 100ton, and the pressure can be adjusted.
3. The outlet shapes of our shisha charcoal machine are lot and we can customized the different shapes as your requirement.
4. Automatic feeding and discharging system.
5. The mold can be easily changed to make different shaped of shsha charcoal, and we can customize the mold as your requirements.
6. The thickness of briquettes can be adjusted, and the pressure can be easily controled.
7. Touching controlling system and full English operation system to make the hydraulic machine easily operated.
8. Position sensor system to make sure the machine changing the molds and maintain easily and perfect working.
9. There is automatic cleaning brush for hydraulic machine to avoid the charcoal dust stick on the molds
10. Manual or automatic working.
Parameters:
Model |
LTYJ-9 |
LTYJ-48 |
Applicable materials |
charcoal powders, coal powders, sawdust, any powders materials |
|
Capacity |
11-16 pieces / time 20-40 times/min |
48 Pieces per Time (30 mm) 8-20 times/min |
Motor |
7.5 kw (4 pole) |
18.5kw (4 pole) |
Diameter of briquettes |
20,25,30 33 35 38 40 43 mm(round); 20-40 mm(cubic) |
20,25,30 33 35 38 40 43 mm(round); 20-40 mm(cubic) |
Feeding materials |
< 3 mm |
< 3 mm |
Briquettes shape |
Round shape and Cubic shape Or as customers’ request |
Round shape and Cubic shape Or as customers’ request |
Pressure |
40-60tons(adjustable) |
40-150tons |
Press type |
Mechanical Press |
Hydraulic Press |
Overall size |
2500x 950x1550 mm (includes conveyor) |
3500*2000*1800mm (includes conveyor) |
Packing size |
1500x1200x1750 mm |
2100*2100*1900mm |
Weight |
1500 KG |
5500kg |
