2015 hot saling auto packing machine
The Vertical/ stand up auto packing machine:
1)This stand up auto packing machine with PLC control, English and man-machine interface.operating easy simple maintain.
2)Advanced photoelectric sensor tracking system and servo motor pull for precise bag width and position of film.
3) can be used to pack powder, granule, rice, maize, foodstuff, feedingstuff, etc.
4) The size and weight can be adjusted. easy and fast adjustment of change over, the machine has strength extensibility, could fill two or even more products into one bag by added filling device.
5) smooth performance and low noise, perfect package appearance, Sensible safety device and no pollution during production to get Friendly working environment.
Characteristics:
- Use the screw to feed the material, to make the weight deviation as small as possible, the average deviation is about ±1g.
- The machine use the servo motor (also can use the stepper motor)
- The stepper motor control the bag pulling to make it more accurate.
- Whole body is made by stainless steel
- Used the variable speed adjusting.
Technical parameters:
Model | DF-50BLG |
| size of making a bag(mm) | L 50-135 W 40-140 |
| form of making a bag | back sealing/three side sealing |
| range of measurement | 10g-180g |
| porduction capability | 40-70 bag /min |
| external dimension (L*W*H) | 700*1000*1700(mm) |
| total power | 2.5KW |
| weight | 250Kg |
Suitable for tableware, paper boxes, books, crafts, toys, mosquit coils, noodles, hardware tools,
stationery, office suppliers, kits, cosmetics and other food, medicine, daily chemical, and metal
industry products.
Outstanding features:
Sealing part:
1.auto packing machine adopt the anti-stick high temperature thermostat aluminum alloy sealing knife, without dis-
connection, non-coking, no smoke, zero pollution.
2. Conveyor take out the completed goods automatically, the delivery time is adjustable.
3. Cutter is with automatic protection function, effectively prevent mistakenly cutting of goods,
make sure the security of the operator.
Tehnical parameters:
| Model | LTM-15545 | LTM-D4520 |
| Packing size (ml) | L500xW350xH120 | W450xH200 |
| Sealing size (ml) | L500xW450 | / |
| Motor power (kw) | 1.30 | 8.5 |
| Working efficiency | 1200-1600 packages / hour | 0-15m/min |
| Voltage | 220v 50-60hz | 380v, 50hz |
| Weight (kg) | 260 | 210 |
| Size (mm) | 1700x900x1400 | 1600x730x1400 |
