Specifications
hydraulic pressure automatic sesame oil press machine1.30 years experience
2.high yield efficiency
3.12 months warranty
Multi-function hydraulic pressure automatic sesame oil press machine
Brief introduction of sesame oil press machine:
When operating, the good processed oil material into the pressing chamber fom hopper, and the screw rotate
to push-in the material for squeezeing. For the material is conducted in the motion state, under high pressure
of chamber, the material, screw, and chamber have a great friction resistance, wh Multi-function hydraulic pressure automatic sesame oil press machine ich resulting in relative motion.
On the other hand, due to te screw diameter is grudually thickening, the screw pitch is gradually declining, so
when the screw rotating, the thread can move the embryo forward, also an flip them outward, at the same time
the material close to the screw can rotate with the thread. So every embryo is with different speed and direction
moving, with the moving between embryo, all the friction generate heat satisfy the needs of oil process operation,
helps to denaturation embryo protein, destorys the colloid, increases the plasticity, also reduces the viscosity and
easy to precipitate oil. Thus increasing the yield efficiency.
Outstanding features of sesame oil press machine:
1. High yield efficiency--comparing with original oil press machine, the normal yield efficiency higher of 4-6%. One
hundred catties peanut will produce 4-6 catties more oil than before, so annual economic benefit is very considerable.
2. Energy saving--will reduce electric power of 40% of te same output, if it saves 6kw an hour, then 30 yuan electricity
fee saved for a day's production.
3. Labor saving--will reduce labor force for 60% of same production, 1-2 people is can organize, which saves labor cost
for 40 yuan.
4. Broad-spectrum--one machine can serve seceral purposes, more than 20 kinds of oil crops cam be squeezed by it, such
as soybean, peanut, sesae, rapeseed, sunflower seed, til seed, etc. 3 levels squeezing, once completely squeeze all oil out.
5. Oily pure--vacuum filtering residue, ensure the purity of oil, conform to the health and quarantine standards.
6. Small area covering--oil mill needs only 10-20 square meter can satisfy the production.
Technical parametes:
| Model | LTM-80 | LTM-100 | LTM-120 | LTM160 |
| Screw diam | Φ 81 MM | Φ 100MM | Φ 120 MM | Φ 160MM |
| Spril speed | 47 R/MIN | 38 R/MIN | 35 R/MIN | 32 R/MIN |
| Power | 5.5 KW (Y132-4) | 7.5 KW (Y132-4) | 11 KW (Y132-4) | 15 KW (Y132-4) |
| Vacuum pump power | 0.55 KW (Y802-4) | 0.75 KW (Y802-4) | 0.75 KW (Y802-4) | 0.80 KW (Y801-4) |
| Heater | 2.2 KW | 2.2 KW | 2.2 KW | 2.2 KW |
| Handling capacity | 65-130Kg/h | 140-280Kg/h | 250-400Kg/h | 300-550Kg/h |
| Total weight | 880Kg | 1250Kg | 1500Kg | 1800Kg |
| Dimension | 1500X1200X1750 MM | 1700X1300X1850 MM | 2000X1300X1500 MM | 2100X1300X1600 MM |
Maintenance of sesameoil press machine:
1. Check the lubrication situation when work for 50 hours, the grease cup on the reducer case can nt be short of
oil, buttering the screw hole each time, drying grinding is forbidden.
2. The lubrication parts should prevent dust and other impurities from invading, reducer motor engine oil quality
should be checked once a year, found that bad, should be changed.
3. When squeezing amount is reduced, the cake and oil discharge is not normal, should tale out squeezer shaft,
check squeezer, pressing bar, discharging ring worn conditis, the worn parts change in time.
4. After working per shift, you should remove the residual cake, clean the dust and oil dirtieson the surface.
5. When needed long-term storage after the production season, should have a maintenance, and unpick and wash
the squeezer, pressing bar, cake discharging ring, and oil them again, put in dry place.
Working principle:
The reference table of automatic oil press machine:
| Name | Weight (kg) | Oil extraction rate (%) | Oil production (kg) | After-oil cake (kg) |
| Peanut kernel | 200 | 48% | 96 | 102 |
| Soybean | 200 | 15% | 30 | 168 |
| Vegetable seeds | 200 | 38% | 76 | 122 |
| Sunflower seed | 200 | 41% | 76 | 122 |
| Sesame | 200 | 50% | 96 | 102 |
After oil cake:
Deliverying:
Service for customers:
1. Pre-sale service
In service of users: production introduction, technical disclosure, provide solutions, quality assurance.
2. On-sale service
♥. In the process of using the equipments, our company regularly access to the customers, ask the feedback of users to
product quality and using conditions, strive to further improve product quality, comprehensive performance.
♥. Arrange personnel to the users to train relevant personnel for using equipment, troubleshooting, debugging and
maintenance of specialized training.
3. After-sale service:
♥. Equipment (in normal use) within the warranty period, has warranty services. Whole machine warranty is 12 months,
expect wearing parts.
♥. To the problem of customers' complaint about quality, immediately reaction, the marketing services personnel in 8
hours to the scene, in the province within 24 hours, 48 hours for domestic and foreign countries within 72 hours.
Certificates:
Workshop:
The interactions between us and our customers:
Year after year, customers from different countries come to us to check the performance. After using our machines, they
will retroaction the using conditions and give their precious opinions to us. The mutual trust and cooperation between us
promoting our enterprise keep growing. Thank you very much for the encourage and help, we will never stop to improve
the quality of our products and design new types to repay our old and new customers, give you a satisfactory answer.
Welcome sincerely to our company to build business internations!
