Specifications
zinc ore pellet machine1. Hydraulic/physical press
2. Low water/power/space consumption
3. High strength/densit
The "Lantian" brand wood pellet making machine is a new type of powder material granulation equipment. It adopts high quality anti-corrosion and wear-resistant materials elaborate manufactured, has perfect appearance, simple operation, low energy consumption, long service life, high pelleting rate, etc. Is now the advanced granulation equipment, and the most popular
granulation machine.
Main characteristics of Lantian zinc powder pellet machine:
1. Wide use, and the strength of granule is adjustable according to material.
2. The diameter of granule is optional, high molding rate, intact particle shape.
3. High strength, transport, measuring and packaging accurate and convenient.
4. Compact structure, simple operation, short process, low failure rate.
5. Large elasticity of operation, the adaptation scope is wide, the size of the extrusion pressure can be adjusted by hydraulic pressure.
6. The zinc powder pellet making machine high level of automation.
The operation principle:
This series wood pellet making machine operation principle is: the motor drive the belt and pulley through reducer passing the power to the driving shaft, and the driving shaft through the open gear synchronization with the driven shaft, extrusion granulation.
Technical parameters of zinc ore pellet machine:
| Model | LT220 | LT290 | LT400 | LT500 |
| Grabule diam (mm) | Φ2- Φ20 | Φ2- Φ20 | Φ2- Φ20 | Φ2- Φ20 |
| Power (kw) | 7.5-11 | 11-15 | 15-18.5 | 22-25 |
| Output (t/h) | 0.5-0.8 | 1-1.5 | 2-2.5 | 3-5 |
| Preloading power (kw) | 7.5 | 7.5 | 11 | 15 |
| Regulator device | Mechanical or hydraulic | Mechanical or hydraulic | Mechanical or hydraulic | Mechanical or hydraulic |
The rollers and granule samples of zinc ore pellet machine:
Notice for using wood pellet making machine:
1. This machine should be started under no-load condition, started with material is forbidden.
2. Strictly prohibit that material with iron into the machine, so as not to break the roller.
3. Before starting the gear part should be redictors oil.
4. The chain and sprocket wipe redictors oil every 7 days.
5. Bearing seat redictors of oil once every three months.
6. The reducer must add gear oil before started, every four months changing gear oil once.
The handling of pellet wood making machine normal issues:
| Issues | Reasons | Methods of handling |
| Ball socket circumferential displacement | A: complete set of bolt looseness B: roller and shaft loose | A: adjust the stock and tighten the belt B: replace the roller or shaft |
| Can not molding ball or just molding pie shape | A: underfeeding B: excessive clearance C: clearance middle is big and two ends small | A: meet the feeding B: adjust gap between rollers C: grind off two ends, smaller the gap |
| Not discharging ball | A: high moisture content B: ball pressure intensity is not enough C: the new mould of rough surface | A: using dry material B: Reducing gap of two rollers C: abrasive grinding |
The interactions between us and our customers:
Year after year, customers from different countries come to us to check the performance. After using our machines, they will retroaction the using conditions and give their precious opinions to us. The mutual trust and cooperation between us promoting our enterprise keep growing. Thank you very much for the encourage and help, we will never stop to improve the quality of our products and design new types to repay our old and new customers, give you a satisfactory answer.
Workshop:
< We promise: >
1. Manufacturing high quality products:
From material purchasing to the finished products: we strictly according to the National Quality Inspection Standards, not only the shisha tablet machines, but also the ancillary equipments for the whole production line.
2. Be good faith producers:
Our quality is consistant, what we are doing just what we have been saying, what you need to do is to rest assured use our machines and equipments.
3. Warm and thoughtful service:
♥. Pre-sale service: design and manufacture machines for you as your requirements, provide you with project, process design, and purchase programm.
♥. On-sale service: accompany you to check the performance, and finish the shipment.
♥. After-sale service: engineers are available to install the equipments, commissioning and training operators on site.
Our Factory:
