Specifications
sawdust charcoal coal briquette pressing machine1. CE and ISO certificates
2. 30 years of experience
3. Capacity of 2-4t/h
Manufacturer Sawdust Charcoal Coal Briquette Pressing Machine
Brief introduction of the sawdust charcoal coal briquette pressing machine:
The "Lantian" sawdust charcoal coal briquette pressing machine is mainly used for pressing coal powder,
coal slime, lignitous coal, ect, the materials. The charcoal ball press machine can make the coal powder one-
time molding, high productivity, good hardness, has been come into used in many power plant, coal washery,
coal briquette molding plant, has good effects.
Raw material:
Coal and charcoal powder, zinc oxide, lead oxide, calcium chloride, calcium phosphate, High test
bleaching powder, cryolite, chemical inhibitor, silica, Isophthalodinitrile etc.
The operation principles of sawdust charcoal coal briquette pressing machine:
The sawdust charcoal coal briquette pressing machine operation principles is like this: the power produced
by the motor, through the V belt to the reducer, then through the coupler to the drive shaft, then by a pair
of open gear, to ensure the two rollers synchronous (constant speed reverse).
The simple flow: Motor → V belt → Reducer → Coupler → Open Gear → Rollers.
Production flow:
The samples and the application of briquettes:
With the improvement of people's aesthetic concept, and the advocating of environmental protection
and energy saving, our factory design and develop a series of new types of ball press machine, and
all types with many different kinds of rollers, any shape you need, we will create it for you!
The technical parameters of sawdust charcoal coal briquette pressing machine:
| Model | Roller Diam (mm) | Production Capacity (t/h) | Motor Power (kw) | Regulator Device |
Spherical Size
|
| 290 | 290 | 2-3 | 5.5 |
Mechanical Pressure Regulating |
User Setting |
| 360 | 360 | 4-6 | 7.5-11 |
Mechanical Pressure Regulating |
User Setting |
| 450 | 450 | 6-8 | 11-15 |
Mechanical Secondary Compression |
User Setting |
| 500 | 500 | 8-11 | 18.5-22 |
Mechanical Secondary Compression |
User Setting |
| 650 | 650 | 11-18 | 22-25 |
Mechanical Secondary Compression |
User Setting |
| 850 | 850 | 20-35 | 30-75 |
Mechanical or Hydraulic Adjustment |
User Setting |
| 1000 | 1000 | 40-70 | 75-130 |
Hydraulic Pressure Adjustment |
User Setting |
Processing of moulds:
Machine pictures:
Certificates:
Foreign customers in our company:
Business negotiations:
Any question, please feel free to contact me! Welcome sincerely to our
company to test our machines and have business negotiations!
