Stable performance aluminum scrap ball press machine

Specifications

aluminum scrap ball press machine
1. CE and ISO certificates
2. 30 years of experience
3. Capacity of 2-4t/h

Stable Performance Aluminum Scrap Ball Press Machine









Introduction of aluminum scrap ball press machine of "Lantian" brand:

The "Lantian" aluminum scrap ball press machine is a kind of briquetting equip

ment, to compress one or more powder material mixed with a certain proportion

of binder, into briquettes which with certain shapes and physical and chemical proterties. This machine is a kind of energy conservation and environmental

protect project, saving cost, creating huge benefits.

What's the material of "Lantian" aluminum scrap ball press machine:

To enhance pressure intensity, our machine moulds all adopts 65mn manganese,

9 chrome molybdenum forging, hardness more than 60 level, use high wear-resis

tant soal processing technology, service life increasing 5-8 times.

Operation principle of aluminum scrap ball press machine:

The motor power through V-belt, is sent to the reducer, and then through

coupler to the drive shaft, then by a pair of open gear to ensure the rollers

synchronous (constant speed reverse).

Motor → V belt → Reducer → Coupler → Open Gear → Rollers.

Application of aluminum scrap ball press machine:

1. The shapes of briquettes: square, oval, goose egg, circular, pillow, bread,

cylinder, etc. You can also has your own ideal shapes, we will make the moulds

as your requirements.

2. Application: for coal, charcoal, chemical engineering, metallurgy, building material,

plastic, ceramics, cast, etc, sectors.

3. Size: in a certain limits can be devided by yourself.

Technical Parameters:

Model	Capacity (t/h)	Roller diam (mm)	Motor power (kw)	Pressure (t)	Roller speed (r/min)	Briquette size
LT-290	1.5-2	290	5.5	18-20	15-17	Users setting
LT-360	2.5-3.5	360	7.5	20	15-17	Users setting
LT-450	4-5	450	15	24	15-17	Users setting
LT-500	6-8	500	22	25	15	Users setting
LT-650	10-15	650	30	30	15	Users setting
LT-850	25-35	850	37-45	54	13	Users setting
LT-1000	35-40	1000	75-90	60-77	12	Users setting

Auxiliary Equipments of the Whole Production Line:

The briquette machine of "Lantian" auxilliary equipments have feeder, crusher,

mixer, conveyor, etc. Different production line the configuration of equipment is

also different, the whole line can be fully configured to fulfill automatic producing,

saving labor, bring more benefits to the enterprise.

Crusher:

Crushing is the first step for making iron briquettes, the powdery material

should be less than 1mm, and the size is controllable by adjusting the air-fan.

Crushed material dust will all keep in the tank without losing or dropping.

Mixer:

Mixing is the second step for making charcoal briquettes, our wheel mill

machine is a really pragmatic mixing device for one can service several

purposes. It has not only the function of mixing iron powder with liquid

binder as usual mixer, but also can press to increase the density of charcoal

dust, so that the final briquettes can be very hard and with good strength.

Dryer:

Drying is the last step of making ball shape briquettes, it is used to drying the

final briquettes which have 15-20% water content duo to the liquid binder, our

vertical type dryer is specially designed for the ball briquettes of mineral material.

Foreign Customers:



Brief Introduction of Our Factory:

Through 30 years of development and technology innvation, our Lantian

Mechanical Plant has developped to a professional manufacturer that set

design, production, and after-sale service as a whole. Year after year, more

and more customers home and abroad have built good relationships with us.
