Wood Sawdust Briquetting Production Line :
Raw Material → Crusher → Dryer → Briquette machine→Carbonization Furnace.
The whole charcoal production line mainly includes four needed machines: crusher, dryer, briquette making machineand carbonization furnace.
1. Crusher:
Crusher is to reduce the size of raw materials at 3-5mm, which is suitable for making the briquette.
This crusher can crush: small tree branch, cotton stalks, tree bark, coconut shell, rice straw wheat straw, corn straw, grass river reeds, palm husk, soybean stalk or husk, coffee husk, paddy straw, sunflowers stalk, bamboo and many other agrowastes etc. And the whole production line can help you make the materials into the excellent wood fibers, flour and sawdust directly, save energy and high efficiency. So the invested cost of the charcoal making can be zero.
2. Dryer:
Air current type dryer is to control the moisture content of raw materials at 8-12%, suitable for making briquette. Too dry or too wet will make the briquette loose, can’t have high density. It is professionally designed for drying different kinds of wood sawdust.
The whole system consists of fan blower, motor engine, fuel boiler, steel pipe, cyclone and air lock. In this sawdust dryer machine system, wet material is input into hopper by screw feeder. Fuel furnace
produces large volume of hot air. The hot air is driven into steel pipes, mixed with wet sawdust and moved through curving pipes and drying chamber by the power of fan blower.
Fast moving hot air sustains and is mixed with raw material sent by spiral feeder in the suspending state through the steel pipe; moisture evaporates as the material traverses along the steel pipe and is rendered dry at the discharge end. Humid air is continuously exhausted, thus the material is dried.
3. Briquette making machine:
Briquetting is a process during which raw materials are compressed under high pressure and high temperature. After the processing of drying and pressing, the briquette is characterized by high density, small in size, better combustion, capable as the substitute for the superior coal or firewood.
4. Carbonization furnace:
Carbonization furnace is to carbonize the biomass briquette into wood charcoal.
Carbonization furnace for biomass charcoal can greatly increased carbonizing ratio (increased from about 88% to 99%) and shortened the carbonizing time (from 24 hours to 6 hours), and shows the features of easy operation, higher safety, high efficiency, and energy saving. This furnace is ideal equipment for wood briquettes to have anoxic distillation carbonization.
(1)Pre-sales service
a. Sales team will suggest suitable project.
b. Technical team analyse and design special molds for you.
c. Pick you up at airport, arrange hotel-booking.
d. Other travel arrangements.
(2)After-sales service
a. Assist you build up factory and production li ne.
b. Install and maintain machines.
c. Training your workers to achieve skillful operation.
d. Offer technical support through telephone or online videos at any time.
(3)Our shipping terms
We can accept EXW FOB and CIF terms. Also our freight forwarding has high effieiency and quick shipping speed.If stock machine,we can send out your products within 5 days.If you need special molds or customized producion line, the delivery time according to you machine quantity, but we will send out as soon as possible.
(4)Our payment terms
T/T, L/C, Western Union or others.
Established in 1980s, our plant has undergone more than two decades of arduous struggle to forge ahead and has developed to be a professional manufacturer in producing equipment. from material purchase to the finished products, all strictly according to the national quality inspections standards.It mainly specilize in charcoal making machine, sawdust briquette machine,briquette machine,powder making machine,extruder machine, BBQ machine,honeycomb briquette
machine,carbonization furnace,heat pump dryer and so on.
