Lantian brand Kaolin Clay Rotary Dryer from Lantian Factory
1.The Best Sale of Wooden Sawdust dryer
Intridution of the Best sale of Wooden sawdust dryer
Working Principle of the Kaolin Clay Rotary Dryer from Fuyu
the raw material plate which is arranged reasonably with changeable angles in order,throws moisture materials into the rotary cylinder. Then water will be separated from the materials by hot air-flow and changed into vapour to be discharged into the atmosphere. Then the materials would be dried.
2.Main Features of the Kaolin Clay Rotary Dryer from Lantian
1.Adopt multiple combination scatter device:Overcome traditional dryer "wind hole" phenomenon, high thermal efficiency, coal consumption reduced about 20%.
2. Apply a variety of combustion furnace: high temperature fluidezed bed, grinding coal powder spraying furnace and artificial add stove.
3.Big and small transmission gears adopt pin column replaceable gear, instead of traditional steel casting gear, saving investment cost, and greatly reduce the repair cost.
4.Adopt centralized control system, which can realize large-scale enterprise microcomputer central control management.
3.Principle and Operation of Stainless Dryer Machine
The raw material plate is arranged reasonably with changeable angles in order, throws moisture
materials into the rotary cylinder. Then water will be separated from the materials by hot airflow
and changed into vapour to be discharged into the atmosphere. Then the materials would be dried.
4.Specification of airflow type wood sawdust dryer:
1. The dryer is suitable for drying materials of moisture 20-70%.
2. This wood sawdust dryer is suitable for drying materials like sawdust, rice hull, milling wheat straw, corn stalks and so on.
3. This wood sawdust dryer is equipped with two fuel boilers, inlet, steel pipe, exhaust blower (fan), air lock and cyclone.
4. Wet materials are input into the hopper. The fuel boiler generates hot air which mixes with wet materials and then is sucked into the pipes by the exhaust blower (fan) quickly. And then hot air is flowing and going though the curving pipes and buffer (drying chamber) of dryer, thus wet materials is finished to dry, and the dried materials are discharged from the outlet with air lock.
5. This sawdust dryer reduces the moisture to 8-12%.
6. Clients can change the angle of dryer base on the production field.
7. This dryer is usually used for biomass charcoal making plant and pellet making plant.
5.Reference Data of the Stainless Dryer Machine
| Model(mm) | Inclination(%) | Rotate Speed(r/min) | Air Inlet Temperature(°c) | Powder(kw) | Production Capacity(t/h) | Weight(t) |
| 600x600 | 3-5 | 3-8 | ≤700 | 3 | 0.5-1.5 | 2.9 |
| 800x800 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.0 | 3.5 |
| 800x1000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.5 | 4.5 |
| 1000x10000 | 3-5 | 3-8 | ≤700 | 5.5 | 1.0-3.5 | 5.6 |
| 1200x12000 | 3-5 | 3-8 | ≤700 | 11 | 2-6 | 14.8 |
| 1500x12000 | 3-5 | 2-6 | ≤800 | 15 | 3.5-9 | 17.8 |
| 1800x1400 | 3-5 | 2-6 | ≤800 | 18 | 5-12 | 22 |
| 2200x16000 | 3-5 | 1.5-6 | ≤800 | 30 | 12-25 | 36 |
| 2400x18000 | 3-5 | 1.5-5 | ≤800 | 37 | 18-30 | 52 |
| 3000x25000 | 3-5 | 1.5-5 | ≤800 | 75 | 32-40 | 86 |
Your Questions and Our Response about the stainless dryer
1.What the stainless dryer machine can be used for ?
Thisdryer can dry many kinds of materials which contain moisture, such as coal,
coal slurry, slag, industrial waste, and clay stone. They are widely used in building
materials, metallurgy, and chemical industry.
2.What is the advantage of the stainless dryer machine?
.♥ The stainless dryer machine in lantian adopts smultiple combination scatter
device so as to overcome traditional dryer "wind hole" .In addition, the stainless
dryer machine posses high thermal efficiency and less coal consumption that reduces
resources about 20%.
.♥ The stainless dryer machine in lantian has big and small transmission gears which
adopt pin column replaceable gear instead of traditional steel casting gear so that it reduces investment cost, maintainces cocst as well as your time.
