Specifications
Seed coating machineSize (length * width * height): 2400*920*2350 mm
Productivity: 5000 kg / h
Power: 2.43kw
Seed Coating machine
Advantage
- Continous fixed quantity material input, continuous fixed quantity medicine supply control
- Lengthened stainless steel roller
- High speed centrifugal throwing disk atomizing technology
- The electronic control system has protecting functions against both overloading and overheating
Brief Introduction:
PY5BYX-5seed coating machine uses rotary quantitative feeding device, continuous gives the material with continuous injecting quantitative drug liquid, which is controlled by drug liquid flow controller, and it called “continuous quantitative type of drug supplying”, so it give an accurately proportion of seed and drug liquid, and easy for adjustment. According with high speed centrifugal disc (for atomizing the drug liquid) and large stainless steel cylinder(for mixing), give a good coating effect. This machine has many advantages, such as good working conditions, good air tightness, safety, reliable, very low seed damage rate, electronic control system for overload and overheating protection.
Technical specification
| Model | PY5BYX-5 |
| Productivity(Base on wheat) | 5000 kg/h(Can adjustment for 3t,4t and 5t) |
| Size( L×W×H ) | 2504×988×2434 mm |
| Drug liquid box size ( L×W×H ) | 540×490×862 mm |
| Power | 380V 50Hz |
| The total power | 3.18 Kw (Include bucket elevator) |
| Drug-material proportional range | 1:25~1:120 |
| Coating uniformity degree | ≥ 98% |
| Broken rate | ≤ 0.1% |
| Auto cleaning machine rate | ≥ 95% |
| Work reliability | ≥ 98% |
| Atomization method | High speed centrifugal throwing atomizing disk |
| Movable(fixation) | Movable/Fixation |
| Lifting way | Bucket elevator |
Note: The capacities may vary depending on seed condition, moisture content, seed varieties, types and volumes of contaminants to be separated and percentage of foreign material acceptable in the final product.
