Home > Industrial Equipment & Components > Engine & Part > Engine > 9Hp and 13Hp 4 Stroke Horizontal Shaft Gasoline Engines
US$ 70 - 175
MOQ: 200 Sets
Key Specifications
Get Latest Price
Usage:
Automobile
Fuel:
Gasoline
Stroke:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
9HP Gasoline Engine With New OHV Valve DesignUS$ 120 - 150MOQ: 200 Sets -
9Hp OHV Air Cooled Single Cylinder Horizontal Shaft Gasoline EngineUS$ 120 - 150MOQ: 200 Sets
-
Air-cooled OHV Single Cylinder Gasoline MotorsUS$ 70 - 175MOQ: 200 Sets
-
Recoil Start Gasoline Engine With CE and EPA CertificateUS$ 299 - 399MOQ: 200 Sets
-
Range From 3.7kW to 8.2kW Portable Gasoline Engine With Horizontal ShaftUS$ 70 - 175MOQ: 200 Sets
Usage
Automobile
Fuel
Gasoline
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Start
Electric Start
Place of Origin
Liaoning, China
Brand Name
Puyang
Model Number
PF173F, PF188F
Warranty
12 months
Specifications
Power: 9HP and13HPEngine type: 4-stroke, air-cooled
TCI ignition system
CE, EPA Certificate
12 months warranty
9Hp and 13Hp 4 stroke horizontal shaft gasoline engines
- Power: 9.0HP and 13HP
- Engine type: 4-stroke, air-cooled
- TCI ignition system
- CE, EPA, CARB and E-Mark certificate
- 12 months warranty
The engine is made with military technology with highest quality. It is powerful, and can go work smoothly. In a word, the engine has an excellent comprehensive performance. The crankshaft output can be fixed with different clutches for different purposes. The machine is widely used on the power sprayer and pressure washers, and it has gained CE and EPA certificates, and it has been exported to all over the world, winning a good mouth.
| Model | PF177F(9HP) | PF188F(13HP) |
| Engine Type | Air-cooled 4 stroke OHV Single Cylinder Horizontal Shaft | Air-cooled 4 stroke OHV Single Cylinder Horizontal Shaft |
| Bore×Stroke(mm) | 77×58 | 88×64 |
| Displacement(cc) | 270 | 389 |
| Compression Ratio | 8.2:1 | 0.334027778 |
| Max Output(kw/4000r/min) | 6 | 8.2 |
| Fuel Consumption(g/kw/h) | 374 | 374 |
| Oil Capacity(L) | 1.1 | 1.1 |
| Fuel Capacity(L) | 6 | 6.5 |
| Ignition System | TCI | TCI |
| Net Weight(Kg) | 25 | 31 |
| Package Size(mm) | 500×430×460 | 500×430×490 |
Pictures in Detail:
1. Side cover of PF177F
2. Side cover of PF188F
3. Output drawings:
