2.5Hp to 15Hp Gasoline engine with CE and EPA Certificate

Specifications

Power: 2.5HP to 15HP
Engine type: 4-stroke, air-cooled
TCI ignition system
CE, EPA, CARB and E-Mark certificate

2.5Hp to 15Hp Gasoline engine with CE and EPA Certificate

• Power: 2.5HP to 15.0HP
• Engine type: 4-stroke, air-cooled
• TCI ignition system
• CE, EPA, CARB and E-Mark certificate

 Strong power and reliable quality with low noise level
Cast iron cylinder, more wear-resistant
Easy start system with low fuel consumption
Oil alert avoids engine damage in the low oil level condition
One year warranty with free spare parts





Model	PF154	PF168	PF168-2	PF170	PF188	PF190
Engine Type	Air-cooled, 4-Stroke, OHV, single cylinder, Gasoline Engine
Bore x Stroke [mm]	54x38	68x45	68x45	70*54	88*64	90*66
Displacement Capacity [cc]	87	163	183	208	389	420
Net Horse Power Output [HP]	2.5	5.5	6.5	7.0	13.0	15.0
Fuel Consumption(g/Kwh)	230	290	290	≤374	354	≤374
Ignition System	Transistorized magneto ignition
Starting System	Recoil or Electric starter
Spark Plug	E6TC	F6TC
Lubrication Oil	SAE 10W/30
Governor System	Centrifugal mechanical
Oil volume [Liter]	0.4	0.6	0.6	0.6	1.1	1.1
Fuel Tank Capacity [liter]	1.6	3.6	3.6	3.6	6.5	6.5
Noise Level at 7m(dB)	72	80	80	80	90	90
Gross Weight(kg)	11.5	17	17	20	33	35
Dimension(mm)	397x345x367	417x368x385	417x368x385	417x368x385	542x500x507	542x500x507
20ft Container QTY	594	528	528	528	176	176
40ft Container QTY	1200	1068	1068	1068	384	384
