Home > Products > Gasoline Engine > Single Cylinder TCI System Horizontal Shaft Gasoline Engine (3.7kW to 8.2kW)
Single Cylinder TCI System Horizontal Shaft Gasoline Engine (3.7kW to 8.2kW)
US$ 70 - 175
/ Set
200 Sets(Min. Order)
- Dalian
- Money Gram
You May Like
Product Details
| Usage | Automobile | Fuel | Gasoline | |
| Stroke | 4 Stroke | Cylinder | Single Cylinder | |
| Cold Style | Other, Air-cooled | Start | Electric Start | |
| Place of Origin | Liaoning, China | Brand Name | Puyang | |
| Model Number | PF Series | Warranty | 12 months |
Product Description
Specifications
Power: 3.7kW to 8.2kWEngine type: 4-stroke, air-cooled
TCI ignition system
CE, EPA, CARB and E-Mark certificate
Single Cylinder TCI system Horizontal shaft Gasoline engine (3.7kW to 8.2kW)
- Power: 3.7kW to 8.2kW
- Engine type: 4-stroke, air-cooled
- TCI ignition system
- CE, EPA, CARB and E-Mark certificate
This model has been widely used in some fields, and it is the best matched power of water pumps, tillers and power sprayers. It works stable and can be mended easily. Compared with the products of other suppliers, it is fuel-efficient and much easier to operate. Please read the manual carefully before operating the machine. If you encounter any problems when maintaining and mending the machine, do contact the local distributors or directly contact us as soon as possible. This engine has gained EC and EPA certificates and it is your best choice.
| Model | PF168F (3.7kW) | PF168FA(4.0kw) | PF177F(6.0kW) | PF188F(8.2kW) |
| Engine Type | Air-cooled 4 stroke OHV Single Cylinder Horizontal Shaft | Air-cooled 4 stroke OHV Single Cylinder Horizontal Shaft | Air-cooled 4 stroke OHV Single Cylinder Horizontal Shaft | Air-cooled 4 stroke OHV Single Cylinder Horizontal Shaft |
| Bore×Stroke(mm) | 68×45 | 68×54 | 77×58 | 88×64 |
| Displacement(cc) | 163 | 196 | 270 | 389 |
| Compression Ratio | 8.5:1 | 8.5:1 | 8.2:1 | 0.334027778 |
| Max Output(kw/4000r/min) | 3.7 | 4 | 6 | 8.2 |
| Fuel Consumption(g/kw/h) | 395 | 395 | 374 | 374 |
| Oil Capacity(L) | 0.6 | 0.6 | 1.1 | 1.1 |
| Fuel Capacity(L) | 3.6 | 3.6 | 6 | 6.5 |
| Ignition System | TCI | TCI | TCI | TCI |
| Net Weight(Kg) | 15 | 16 | 25 | 31 |
| Package Size(mm) | 400×330×370 | 400×330×370 | 500×430×460 | 500×430×490 |
