CE 220 volt Celling mounted Infrared electric heater

Specifications

Infrared electric heater
1.Power:800 to 6000W
2.Anodicoxidation tech
3.up to 300degrees in 3 mins
4.Carbon fiber heater

CE 220 volt Celling mounted Infrared electric heater



Features:
(1) Comfortable: No wind, light or odor will be caused during the running of this product, so the indoor air is clean without floating dust.

(2) Energy-saving: This product has high heat generation efficiency and good heat radiation effect, controls the temperature intelligently, and saves power and energy



(3) Reliable: The indoor temperature can be freely adjusted, free of the limitation of heating season. The service life of this product is up to 20 years



(4) Physical therapy: The heat radiant can change body microcirculation, cell organization under skin producing resonance, clearing the barrier of microcirculation, adjusting and balancing nervous system promoting metabolism, increasing body physical power. It is very good for your health



Specification:

Power	Cover area   (m2)	Surface temperature	Dimension(mm)	N/G weight (Kg)	Container load Q'ty (20’/40'/40HQ)
800W	6~8	230~270C	860*270*75	8/9.2	820/1676/1854
1000W	8~10		860*270*75	8/9.2	820/1676/1854
1200W	10~12		860*395*75	10.6/12.2	698/1260/1392
1500W	12~15		860*395*75	10.6/12.2	698/1260/1392
2000W	15~20		1170*270*75	10/11.7	595/1244/1448
4000W	30~40	250~285C	1470*395*75	20/22.8	365/753/824
5500W	40~55	260~300C	1825*397*75	24.5/28	305/615/678
6000W	55~60		1825*520*75	31.9/36	219/444/532





INSTRUCTION METHOD



1. Product must be installed by professional installation personnel, and with national safety standards for electrical installation.
2. Rated voltage and power supply must use dedicated circuit, devices connected to the power outlet must have ground wire.
3. Determine the installation location of radiant heater, check the installation location can support four times of radiant heater weight, it should be reinforced before installation if can not support.
4. Choosing hanging rod bolts, fix 4pcs M8 screws on 4 positions of the bank radiant heater, as picture1.
5. Product can be installed on the ceiling/bracket or hanging installation. Be ensure that the space not less than requirements shown on picture2.
6. Please refer to wiring diagram.
