Infrared Radiant Heating Panels with Installation Instruction

Specifications

Fir radiant heating panels
1.Power:0.8kW to 6kW
2.Heating area:8-60M2
3.Delivery: 10 working days
4.Sample is available

Infrared Radiant Heating Panels with Installation Instruction



 Infrared radiant heater

Infrared heaters use tubular heaters that reach high temperatures and radiate sufficient heat from overhead.Infrared heaters come in many different lengths and sizes and are an excellent choice for outdoor applcaitions.



APPLICATIONS:

--OFFICE BUILDING,
Entryways, Enclosed Walkways and Perimeter Heat With Variable Air Volume Systems.
--INSTITUTIONAL
Classrooms, Cafeterias and Swimming Pool Areas.
--HOSPITAL
Hydrotherapy, Nurseries, Burn and Trauma Areas.
--RESIDENTIAL
Bathrooms, Above Floor To Ceiling Windows and ` Sliding Doors, Other Cold Spot Areas.



For Complete or Supplemental Heating In Commercial, Residential and Institutional Structures
- In New or Remodeled Construction . . .
Clean, Gentle, Comfortable Heat
Great For Offsetting Perimeter Heat Loss . . .
Saving Substantial Energy Over Other Systems By Heating People and Objects rather Than All The Air In a Room or Building.



Series	Model	Specification	Heating Power	Voltage	Heating Area
		Length*Width*Height
		mm	W	V	M2
Residential	PF-NR08-11A	860x270x75	800	220/380	6~8
	PF-NR10-11A	860x270x75	1000	220/380	8~10
	PF-NR12-11B	860x395x75	1200	220/380	10~12
	PF-NR15-11B	860x395x75	1500	220/380	12~15



Series	Model	Specification	Heating Power	Voltage	Heating Area
		Length*Width*Height
		mm	W	V	M2
Commercail	PF-NR20-11A	1170x270x75	2000	220/380	15~20
	PF-NR40-11A	1470x395x75	4000	220/380	20~40
	PF-NR55-11B	1470x520x75	5500	220/380	40~55
	PF-NR55-11A	1825x397x75	5500	220/380	40~55
	PF-NR60-11A	1820x520x75	6000	220/380	55~60
