Foam Concrete Machine
Features:
The foaming machine consist of the pumping system, foam generating system, mixing system, rack, electrical control cabinet.
(1) Pumping system: namely squeeze hose pump
(2) Foam generating system uses a standard modular structure, composed of frequency variable motor, air compressor, water pump, foaming agent gear pump, foam assembly etc.
(3) Mixing system includes the motor, mixing vat, mixer, transmission system, lubrication system etc.
(4) Electrical control system consists of the inverter, AC contactors, air switches, intermediate relay etc.
Main Technical Data:
Item |
Unit |
YJY40 |
Theoretical production capacity |
m3/h |
40 |
Max. Pressure |
MPa |
4 |
Maximum horizontal distance |
m |
600 |
Maximum vertical distance |
m |
180 |
Total Power |
kW |
11 |
Dimension |
mm |
3950×1560×1580 |
