powerful ! BS-35pro hydraulic concrete diamond chainsaw

Specifications

BS-35pro mini chainsaw :
1:portable and durable
2:max cutting 350mm
3: hydraulic system .

mini chainsaw

hydraulic system

BS-35pro/BS-50pro

hydraulic system diamond chain cutting machinery

powerful & efficient

The Hydraulic Diamond chain saw used to cut and quick open hole on collapsed concrete precast panel and reinforced concrete wall in Earthquake rescue and Firefighting rescue application, In order to place life detectors and Lifestyle Article for the trapped people



product pictures:



chainsaw head: hydraulic power unit:



advantage:

1) easy to use : this machine using single operation,and in light weight. 2) Wide operating range : can cut coal coating, concrete, reinforced concrete, pipe, brick,  stone and  wood. The long bar can cut into 350mm deep blind hole to operate. Besides cutting concrete regularly, it can also dig holes in the wall. The smallest hole size: 120×120mm. 3) Special designed : Ergonomic designed handle can reduce labor intensity when operating.  4) No dust : Chain plate is equipped with water pipe to cool and lubricate.  5) High safety: there are special devices to protect operator, it can assure the safety of operator when any equipment fault occurs. In addition, the machine will automatically stop working when the water pressure is lower than 0.2MPa, to avoid the high temperature and spark happening.



project case:



we also have the cutting video of this machine, welcome the customers interested contact us for reference.



technical specification:



model	BS-35pro	BS-50pro
weight of sawhead	11kg
power of unit	5.5kw
voltage	220V
length of bar	500mm	600mm
max. cutting depth	350mm	500mm
blade drive	hydraulic pressure
operating pressure	≤15MP





XI'AN GRAND HARVEST EQUIPMENT CO.,LTD



thanks for all customers interested in our products, we are professional suppliers of concrete cutting machine.



in concrete cutting field,we have wall saw, wire saw, chainsaw , hydraulic drill, hydraulic concrete crusher, hydraulic splitter, etc.



Our products are sold in Russia , India, Lebanon and well appreciated by their purchasers due to their high quality and reasonable price.We will do better and orders are welcome.

packing : plywood case

delivery time : depending



one year warranty for our all products



payment terms:

1) 100% T/T in advance for amout less than

USD10000.00

2) 30% payment paid by T/T in advance and 70%

payment paid by T/T befor delivery for amout more

than USD10000.00



contact :
