Specifications
HWS-500TM concrete pipe cutting machine:1:portalbe
2: max. cutting depth:62cm
3: durable .
concrete pipe cutting machine
easy operate
BS-500TM/600TM
construction concrete wall cutting tools
world famous & high quality
about our machine:
BS-500TM wall saw machine is widely used in mineral mining(cave mining) , civil engineering construction and demolition. It is also an indispensable tool in construction, river dredging, salvation etc. Our main Models of hydraulic pump and cylinder are as follows. If you are interested in, please let us know which type of pump and cylinder you need. We will offer a very competitive price for you.
1) Powerful, it can split the stone or concrete easily.
2) High Efficiency, it can split the stone in 5-10 seconds.;
3) Long-life, the wedges stands wear and tear;
4) Easy to operate and maintain
technical details:
model |
HWS-500TM | HWE-600TM |
| rated input | 30HP(22KW) | 34HP(25KW) |
| voltage | 380V/400V,3-phase,50HZ | 380V/400V,3-phase,50HZ |
| current | 43A | 48A |
|
weight hydraulic power unit incl.oil |
170kg | 175kg |
| dimension of power unit | 650*550*1000mm | 650*550*1000mm |
| max.operating pressure | 200bar | 240bar |
| max starter blade | 800mm | 800mm |
| blade diameter range | 800-1400mm | 800-1600mm |
| max. cutting depth | 620mm | 730mm |
| weight of saw head | 34kg | 32kg |
| control type | hydraulic auto | hydraulic auto |
| blade rotational speed | 900rpm | 400/860/1200rpm |
pictures for reference:
|
blade: saw head:
accessaries:
|
project case:
one year warranty for our all products
payment terms:
1) 100% T/T in advance for amout less than
USD10000.00
2) 30% payment paid by T/T in advance and 70%
payment paid by T/T befor delivery for amout more
than USD10000.00
note:
All the listed price is only for references , for latest
price please contact us directly.
