High efficiency !!! BS-500TM Concrete wall cutter machinery with hydraulic pressure
About our machine:
BS-500TM/600TM wall saw machine is widely used in mineral mining(cave mining) , civil engineering construction and demolition. It is also an indispensable tool in construction, river dredging, salvation etc.
Advantage:
1) Powerful, it can split the stone or concrete easily;
2) High efficiency, it can split the stone in 5-10 seconds.;
3) Long-life, the wedges stands wear and tear;
4) Easy to operate and maintain.
Technical details:
model |
BS-500TM | BS-600TM |
| rated input | 30HP(22KW) | 34HP(25KW) |
| voltage | 380V/400V,3-phase,50HZ | 380V/400V,3-phase,50HZ |
| current | 43A | 48A |
|
weight hydraulic power unit incl.oil |
170kg | 175kg |
| dimension of power unit | 650*550*1000mm | 650*550*1000mm |
| max.operating pressure | 200bar | 240bar |
| max starter blade | 800mm | 800mm |
| blade diameter range | 800-1400mm | 800-1600mm |
| max. cutting depth | 620mm | 730mm |
| weight of saw head | 34kg | 32kg |
| control type | hydraulic auto | hydraulic auto |
| blade rotational speed | 900rpm | 400/860/1200rpm |
As to wall concrete cutting machine , we have two model :500TM and 600TM for ur choice.
whichever model is suitable for u, pls contact us freely, and we will offer a very competitive price for you.
Pictures for reference:
|
Power unit:
Blade: Saw head:
Accessaries:
|
Project case:
All the listed price is only for references , for latest price please contact us directly.
If you have needs and are interested with our machine, pls contact with me freely about the more details and video and I am of service all the time!
