Brief introduction of the plant
Using dry peeling and degerming technology, it can produce different sizes of corn grits and flour at the same time. Corn grits size can be customized as per customers' need in order to meet various of needs such as brewery, snack food, glucose, sugarhouse. Thanks for the dry peeling and degerming technology, husks and germs collected at the end don't need to dried before used for animal feed.
Raw material: corn, maize
Color: depend on customer
Product: grade flour, grade grits, feed powder
Material: stainless steel
Origin: Henan, China
Production capacity: 20t/d to 200t/d
Main part: bucket elevator, vibrating sifter, de-stoning, magnetic selector,peeling crusher, polishing machine, grits making machine, milling machine,fan.....
Features of the producing line
♦The machine adopts full steel structure, featuring handsome appearance, easy installation and small occupation.
♦ It has stable performance and high flour yield, able to process high quality corn slag and corn flour. The flour screening adopts efficient double-bin plansifter; the screen adopts stainless steel wire mesh, difficult for blocking.
♦The whole machine adopts pneumatic and negative pressure transmission, not only preventing smell from leakage, but also reducing workshop dust and drying the flour in this process.
♦The air outlet of the blower can be equipped with pulse deduster, making your working environment cleaner.
Technical parameters
| MODEL | MATCHING POWER (KW) | CONSUMPTION (KW/H) | PRODUCTION (T/D) | PLANT SIZE L*W*H(m) |
| 30t | 81.4 | ≤46 | 30 | 10*5*8 |
| 50t | 179.6 | ≤46 | 50 | 18*5*8.2 |
| 100t | 312.6 | ≤46 | 100 | 24*7*9 |
| 150t | 478.34 | ≤46 | 150 | 34*7*9 |
| 200t | 768.14 | ≤46 | 200 | 38*7*9.5 |
Product Index
Products: corn gritrs,flour,huskers;
Yields: grade corn flour 25%-30%,
grade corn grits 425-50%
feed powder 22%-30%,
total output of corn grits and flour 75%-80%
Corn flour finess: 40-200 mesh (adjustable)
Processing technique
Raw grain corn after screening,de-stoning are sent to the corn hullers, after hulling, t he material were sent to the polishing machine, after polishing then were sent to grits making machine, through flat sieve,sifting the large, medium and small garde grits, the grits that not conform to the gits requirement were sent to the milling machine, after milling then we can get grade flour. The huskers after collecting then we can package and get feed powder.
Part machines display
bucket elevator
De-stoning machine
Polishing machine
Maize flour milling machine
The whole line of grits and flour line
Final Products
Our commitment
We provide precise design proposal. Including detailed quotation List, CAD flow chat,
technological index, installation diagram,and provide installed production line video and photos for customers reference.
We provide standard shipping wooden package, full set of equipments photos before and after packing goods.also, full set of shipping documets sent by post.
Engineers is available to install machine oversea.
Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes,man-made problems, etc will be responsible for clients-self.
If you need more technical information and exactly price, please contact with us freely.
Our professional technique team will give you the best service.
Pls. contact me if you have any interest in our corn/maize milling machinery.
Thank you!
