New Type High Accuracy Seeds Optical Selector, Color Selecting Machine
- 10 Set / Sets per Month
- Qingdao or Shanghai
- T/T
- Top quality low price destone machine in corn milling mahcines
- High efficiency Vibrating screen with low price
- High efficiency multifunctional specific gravity separator for grain cleaning
- Hot selling multifunctional specific gravity separator for all kinds of cereals
- China best selling grain seeds gravity separator / beans graivty separator
- Small industrial seed gravity separator / beans separator for grain cleaning
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | King Shine |
Model Number: | 5XZ-5 | Production Capacity: | 98% | Voltage: | 220V/380V |
Power(W): | 8.25KW | Weight: | 1300kg, 1300kg | Dimension(L*W*H): | 2600*1560*2100mm |
Certification: | IS0/CE | Warranty: | 12months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
New Type High Accuracy Seeds Optical Selector, Color Selecting Machine
Brief introduction of grain seeds color sorter / grain seeds separator
Colour sorters are machines that are used on the production lines in bulk food processing and other industries. They separate items by their colours, detecting the colours of things that pass before them, and using mechanical or pneumatic ejection devices to divert items whose colours do not fall within the acceptable range
Working principle of grain seeds color sorter / grain seeds separator
The raw cereal seeds will go into the hopper on top of the machine by elevator and then theseeds will flow down along the chutes of colour sorter. Chutes of colour sorting machine will make seeds flow streamlined for scanning by CCD sensors in scanning area, The moment the camera detects any color defects, the camera instructs the ejectors fitted in the machine to open the nozzle. The nozzle is connected to valves containing compressed air. This air is then used to shoot out the color defected material from the input rice. The types of defects in cereal seeds are: black tipped chalky, yellow, mouse droppings, immature grain, etc.
Specification or technical parameter of grain seeds color sorter / grain seeds separator
Name | CF3 | CF5 | CF7 |
Model | 6SXZ-180F | 6SXZ-300F | 6SXZ-420F |
Channels | 180 | 300 | 420 |
Throughput (T/h) | 2~5 | 4~8 | 5~10 |
Voltage(V) | 180~240(50HZ) | 180~240(50HZ) | 180~240(50HZ) |
Power(kW) | 1.8 | 2.4 | 3.5 |
Air pressure (MPa) | 0.6~0.8 | 0.6~0.8 | 0.6~0.8 |
Air Consumption (m3/min) | <3.0 | <4.5 | <6.0 |
Weight(kg) | 940 | 1330 | 1650 |
Dimension (L* W * H)(mm) | 1455 x 1535 x 2142 | 2075 x 1535 x 2142 | 2625 x 1535 x 2142 |
Features or advantages of grain seeds color sorter / grain seeds separator
A.wide range of application: in addition to realize color sorting by visible color spectrum system, also can realize the sorting of infrared sensitive material by using near infrared optical system.
B.combine shape sorting function: according to the characterisics of material, using special image processing algorithm qith shape and color, to realize shape sorting successfully by detecting material’s Circularity rate, linear rate, Perimeter and area, etc.
C.transmission-type color tunable background lamp: use transmission-type background board instead of traditional reflection-type background board, simplified the system, improved the stability. Use RGB color tunable background lamp instead of RGB reflection board, in addition to get red, green, blue color, also can get multi colors by the mixing of RGB lights, widely expanded the colors of background.
Grain seeds application of this color sorter
King Shine Machinery is one professional cereals processing equipment manufacturer and supplier with 20 years experience in design, manufacture, installation, commissioning and training of cereals processing equipment. We keep invest in most advanced equipment and keep upgrading and maintaining the facilities we have had. We can provide our customers with high quality products by combining modern equipment with advanced processing technology and perfect Quality Control System.
Based on Reliable Quality, Reasonable Price, Perfect Service, we have made our equipment enjoy high prestige in the market of Africa, America, Europe and Asia. We have designed and installed our equipment in Tanzania, Ethiopia, Uganda, Bangladesh and etc.
Worshop of grain seeds color sorter / grain seeds separator
We have clean and orderly manufacturing workshop. Manufacture of equipment: Maosheng takes the most advanced processing machine , such as laser cutter , plasma cutter, computer numerical control machine tools, computer numerical bending machine and so on, which guarantee accuracy of machine, reliable work and long durable life.
We also have strict Quality control system to ensure the appearance quality and lifetime of each machine.
All our single equipment will be packed by standard wooden box outside with inner protective film and waterproof membrane outside of the machine to prevent the machine from being wet or damage during the domestic and shipment on sea.
1. What kind of cereals King Shine color sorter applies to?
King Shine color sorter applies to all kinds of cereal seeds, such as corn, wheat, sesame, peanut, chickpea, soybean, red beans, green beans , mung beans, pumpkin seed, white kidney bean, horsebean, almond apricot, oat, quartz sand and etc.
2. How to use the machine?
We will supply the Installation instructions or video and our engineers will train your operators.
3. How long about the guarantee period?
One year. And we supply the software upgrade services for our customers lifelong.
4. Can you supply the air compressor, air tank and air filters?
Yes, we can provide above equipment, our standard offer include color sorter machine with air Compressor, air tank and Filters.
5. Is oversea service available?
Yes, our engineers could travel abroad when required.
6. How to calculate Installation personnel cost?
On condition that customer required to installation, our company would like to send 1 Engineer to guide for installation, then customer should to pay the cost, contain transaction of Engineer’s visa, transportation(air) for go abroad. Also the accommodation , local transportation and security when the Engineer arrived.
King Shine could supply below cereals processing lines
10-1000TPD Wheat Flour Milling Lines
12-500TPD Maize Meal Production Lines,
1-10TPH Beans Cleaning Lines;
1-10TPH Lentil cleaning, peeling and splitting Lines;
2 TPH and above Sesame Cleaning and Peeling Line;
600kg/h-1TPH Rice Mill Lines and etc.
