Polystyrene Food Box Making Machine

Specifications

  Polystyrene Food  box Making Machine

This line is the whole production line, which can form foam tray from raw material. The material is recycled. The work flow is as follows: raw material---(ps foam sheet extrusion line)---foam sheet---(foam tray forming machine and cutting machine)---foam tray---(plastic recycle machine)---plastic granulars( this part can be used as raw material)----foam sheet.

Notice:our factory have published a newest improved production line, this production line can produce both ps foam fast food box and ps ceiling tiles, due to the demand of food container and ps ceiling tiles is increasing. this newest invention have good quality with CE Approved, this production line can produce different sizesof food container,tray,plates and different color and pattern of ceiling tiles, which have met with favorable reception from our customer.

2.PS foam sheet extruder machine

 This PS foam sheet extrusion machine produce PS foam sheet, which is a kind of new-type packing with the features of shock proofing, sound insulating, heat preservation, damp proof, safety, and good plasticity.

This machine includes three types as follow :

 3.Automatic vacuum forming and cutting machine

----This type of developed by combining the domestic equipment and advantages, is a set of hydraulic pneumatic servo drive for an automatic forming cutting seek. Mainly by electrical components, Japan and Germany pump, ensure the reliability of the equipment operation, and can be used for hot forming process PS foam into food container,lunch box,tray,plates,ceiling tiles,etc.


----The biggest advantage is forming cutting integration, reduce work link, produce the product directly, it can be collected in stacking area of work to save time, save the production base and greatly reduces the working intensity save artificially.

a. Max forming area: 1100mm*1200mm

 b. Max forming depth : 130mm

c. Forming mode: Vacuum forming, press forming, mould forming, comprehensive forming

d.Forming pressure: 20t (adjustable)

e.The production efficiency:3- 5 seconds/mould

4.recycling and pelletizing machine

This recycling and pelletizing machine is designed to reclaim the foamed polystyrene and polyethylene materials almost identically to new ones with its own superior filtering performance.
