From 600mm to 3500mm NPD Series Slurry Balanced Pipe Jacking Equipment Cost

From 600mm to 3500mm NPD Series Slurry Balanced Pipe Jacking Equipment Cost thumbnail-1
From 600mm to 3500mm NPD Series Slurry Balanced Pipe Jacking Equipment Cost photo-1
US$ 10,000 - 1,000,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
GEC
Contact Supplier Request Quote Chat Now
Zhengzhou Gaode Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Qingdao or other
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name GEC
Model Number NPD1000
Dimension(L*W*H) 1220*3600mm
Weight 6.5ton, 6.5 Ton
Certification ISO SGS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost

Product Description

Introduction of slurry balanced pipe jacking equipment:

Nowadays many of our cities existing facilities can not meet the requirement of development, it needs to provide better sewage system, water, gas, electricity and communication facilities. The especially important matter is that worker install the pipeline safely and to reduce the destroy of city area. Therefore the pipe jacking machine and skill are very important. Our company could supply safety and economical pipe jacking method for you.

Feature of slurry balanced pipe jacking equipment:



1. High precision: Main machine adopt planetary gear reducer, Siemens motor, powerful, good performance, low noise;

2. No need to lower the underground water level;

3. Go through sandy soil,sludge,clay soil, gravelly soil,decayed rock;

4. φ800mm-φ3500mm various pipe jacking machine;

5. φ4200mm-φ6900mm various rectangle pipe jacking machine.

from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost



Feature of NPD series slurry balanced pipe jacking equipment:



1. wide range of soil conditon, soft soil, clay,sand soil,gravel soil,hard soil,backfill soil;

2. crush capacity is powerful;

3. independent and perfect grouting water and cement system

4. fast speed on pipe-jacking, the most fast speed is 200mm per minute.

5. Rectification Angle is  5.5°, advanced control system to control the machine head, digital display, convenient operation.

Technical data

from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost

Technical data of slurry balanced pipe jacking equipment:



NPD Series Slurry Balance Pipe Jacking Equipment
Model OD*Length   mm Weight Ton Cutter Rectification Cylinder Rectification Angle Power pack for Rectification kw
Motor kw*set Torque T*m Rotating speed rpm Force          T Quantity
NPD600 760*3200mm 3.6 11*1 2.9 5 15 4 0.55° 0.55
NPD800 980*3400mm 5 15*1 2.9 5 26 4 0.75° 0.75
NPD1000 1220*3600mm 6.5 15*2 9 3.3 42 4 1.5° 1.5
NPD1200 1460*4000mm 8 15*2 9 3.3 42 4 1.5° 1.5
NPD1350 1640*4000mm 10 22*2 15 2.8 60 4 2.2° 2.2
NPD1500 1820*4000mm 14 22*2 15 2.8 80 4 2.2° 2.2
NPD1650 2000*4200mm 16 30*2 25.5 2.35 80 4 2.2° 2.2
NPD1800 2180*4200mm 24 30*2 30 2 100 4 2.2° 2.2
NPD2000 2420*4200mm 30 22*4 40 1.5 100 4 2.2° 2.2
NPD2200 2660*4500mm 35 22*4 50 1.5 120 4 2.2° 2.2
NPD2400 1900*4800mm 40 30*4 60 1.5 80 8 2.2° 2.2
NPD2600 3140*5000mm 48 30*4 76 1.5 120 8 3° 5.5
NPD2800 3380*5000mm 52 30*4 76 1.5 120 8 3° 5.5
NPD3000 3620*5400mm 60 30*6 143 1.4 200 8 3° 5.5
NPD3500 4180*5700mm 75 30*6 162 1.2 200 8 3° 5.5



Datailed Images

 from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost



Related products

 NPD series slurry balanced pipe jacking machine:

from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost

Earth pressure balanced rectangle pipe jacking machine:

from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost

from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost

YD Series Rock Pipe Jacking Machine:

from 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment costfrom 600mm to 3500mm NPD series slurry balanced pipe jacking equipment cost



Our Services



1.  Providing proposal according to customer's requirement.

2.  Supply installation and staff training.

3.  One year Guarantee, Life time maintenance and technical support.

4.  Providing spare parts all the life time.

5.  Respond customer's problem within 24 hours.
