GEC Brand Double Cylinders Diesel Hydraulic Power Unit for Engineering Machinery

US$ 3,000 - 8,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Type:

Other, Hydraulic Power Units, hydraulic power unit

Model Number:

GHPP14/68-30D

Brand Name:

GEC

Contact Supplier Request Quote Chat Now

Zhengzhou Gaode Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Tianjin Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Other, Hydraulic Power Units, hydraulic power unit

Model Number GHPP14/68-30D

Brand Name GEC

Place of Origin Henan, China

GEC brand double cylinders diesel hydraulic power unit for engineering machinery

Choose GEC,choose high quality!

Model: GHPP14/68-30D

General type hydraulic power pack is used for driving hydraulic cylinder, hydraulic motor and other hydraulic actuator. Submersible power pack with motor on the top of power pack and pump inside the tank, thus get a compact structure and small volume.

It’s widely used as hydraulic driving for engineering machinery, construction machinery and mining machinery.

Working principle:

Motor or Diesel engine make the oil pump rotate, and the pump absorbs and supplys oil from the oil tank, which can convert the mechanical energy into pressure energy of hydraulic oil.After adjusting the direction, pressure and flow through manifold block, hydraulic oil enters the cylinder or oil motor of hydraulic device by means of the outside line, thus controlling the transformation of the actuator's direction, the power and the speed to make all kinds of hydraulic device work.

Technical data:

Model	GHPP14/68 -30D
Rated work pressure	14MPa
Rated output	68L(18gallon)/min
Rated Diesel Rev.	2600 rpm
Diesel Power	30Kw/40Hp
Diesel Model	Changchai with water cooling(Steam type)
Overall Dimension	1750x1300x1500mm
Weight	550Kgs

Features/Advantages:

1. Changchai steam type water cooling diesel engine;

2. With Wheels, move easily;

3. Powerful, Versatile, Stable and Reliable;

4. Suitable for rough work circumstance;

5. Low noise, fine construction, high quality;

6. Energy saving: perfect design of circuit;

7.Tubing connection between hydraulic pump and hydraulic motor, each other is not subject to strict limits on

space layout;

8.Because of oil as working medium, the components of relative motion between surface can self lubrication, wear small, long service life;

9. Each pump can be used as a mobile station, without any pumping station project;

10. Operate and control simply, high degree of automation.

Detailed Images

Pictures in different angles:

Packaging & Shipping

Our Services

Why to choose us?

1. OEM Service: hydraulic power pack can be designed as your needs.

2. After-sale service: One year warranty, but wearing parts exclude..

3. We not only have advanced processing equipment, but also equipped with a consummate testing facilities and strong technical force.

4. Specialized in manufacturing all kinds hydraulic cylinders, hydraulic station, hydraulic pump.

Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.

We are a member of trade assurance on Alibaba, and our trade assurance amount is USD78000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
