GF20 stirrup rebar bending machine
Brief Introduction:
1) GF20 bender is a rebar bending machine used on construction project. It can bend bar diameter up to 20 mm for Round Steel Bar into Various angles. And it is easy to operate ,with safe working and reliable quality.
2) Two foot switches can be adjusted between 90° and 135° according to the need. Its working efficiency is about 500 pieces per hour with tidy angles under the operation of skilled worker.
2. Main Parameters:
1) Bending round steel diameter,4-20mm
2) Working disc diameter,320mm
3) Bending speed of main axis, 25-30 times per min.
4) Motor power,2.2KW, 380V
5) machine dimension,800*550*850mm
packing size, 860*600*1020mm
6) Weight, NW135kg ,GW150kg
7) packing type, iron frame with carton covered outside
3.Data sheet
Rated bending capacity | 4-20mm |
Bending angle | 90/135 |
Max.bending angle | 180 |
Speed of main shaft | 25-30 r/min |
Motro power | 2.2KW |
Gross weight | 150kg |
