HBT20-10RS big pressure floor screed concrete pump machine
Brief introduction of big pressure concrete pump :
Concrete pumps is a concrete machine to replace the traditional way to lift the concrete by labor force but pumps the concrete through the pipeline, use as conveniently as the tap water.
In order to meet the demand of open country and other no power supply constructions, we research and developed the diesel engine concrete pump. Our concrete pump is set of mechanical, electrical and hydraulic technology as one, with reliable performance of smooth operation and strong pumping capability. The diesel engine is with advanced high quality, low emission, low fuel consumption, meet the advanced standard. Reliability and stability is guaranteed by automatic engine regulation.
Specification of big pressure concrete pump :
Model No. |
HBT20-10RS |
Max. theoretical concrete output (m³/h) |
Low pressure21 / high pressure12 |
Max. theoretical concrete pumping pressure (Mpa) |
Low pressure 5.5 /high pressure 10 |
Theoretical vertical conveying height (m) |
130 |
Theoretical level transmission distance (m) |
350 |
Hopper volume (m³) |
0.4 |
Filling height (mm) |
1100 |
Rated power (kw) |
22 |
Hydraulic oil tank volume |
120L |
Diesel oil tank volume |
80L |
|
Concrete tube conveying diameter (mm) and Max. Aggregate particles (mm) |
Φ76 25mm Φ89 30mm |
Diesel Power |
40KW |
distribution valve |
S valve |
Overall dimension (L×W×H) (mm) |
4300*1670*1680mm |
Total weight (kg) |
2500 |
Feathure of big pressure concrete pump
Intelligent power control system to regulate the engine speed automatically, for smooth and efficient operation
Plunger pump with constant power, to ensure the efficiency of main engine
Good sealing S-valve, installed with floating wear resistant ring
High-quality wear resistant alloy components for long service-life
High delivery pressure for demand of high-rise and long distance projects
Air cooling system, without dependence of external water
PLC system to ensure best control performance
With re-pumping function to smooth construction of better accessibility
Equipped with wired remote controller, easy to operate
Application of big pressure concrete pump :
Conveying heating, heat insulation, light weight foam cement mortar.
Conveying light-weight foam cement, mortar for ground heating, heat insulation.
Conveying and injection of fireproof and heat preservation materials.
Press grouting and filling for all kinds of engineering and construction.
Package of big pressure concrete pump
Packing: In Nude,One unit/20GP
Delivery time: Usually in 10 working days for concrete pump .
Factory directly supply.
Professional sales team and experienced workers.
Competitive price according to good raw material purchasing ability,and high work efficiency
Best manufacturer in China.
Good after-sales service
Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.
We are a member of trade assurance on Alibaba, and our trade assurance amount is USD36000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
Q1: What's the form of distribution valve for concrete pump?
A: Its S valve.
Q2: What about the output you can supply?
A: The output we can supply is from 12CBM/hour to 80CBM/hour.
Q3:The matched pipes or hoses can't meet to our requirement, how can we want more pipes or hoses?
A: Easy, you could tell us before you book it, and we will calculate the cost of the extra ones.
Q4: If over the guarantee, we need spare parts, how?
A: Here, we are always here offer service in 24hours every day.
Q5: How about the power?
Electric power model and diesel power model both can be provided.
Q6: How is concrete pump working in horizontally and vertically pumping?
For horizontally pumping, pipeline is easy to arrange.
For pumping concrete vertically, normally we leave some small holes and space each floor. When the building is finished, the holes and space will be sealed or left for some other function such as water transmission conduit. The steel pipe of our pump is through these holes and space in the buildings. Vertically pipeline via exterior and tied to the scaffold is also convenient.
Q7: Can concrete be pumped up hill?
Portable concrete pump be pumped up and down hill around and under obstacles, through small openings, across large distances and so on. We have been on many different types of jobsites that require different set ups and I'm sure that we will be able to help you out on yours. Just let us know what you require.
Concrete Pump
Mortar Pump
Concrete Mixer
Placing booms
For more information about big pressure concrete pump and floor screed pump, please feel free to contact us.
