cup mineral water filler and seamer machine
The machine finish all works of cup feeding ,filling and sealing automatically .Has the advantage
of high precision filling volume ,PLC touch screen control with English display ,easy to operate ,
automatic adjusting film sealing position with photoelectric sensor feedback correction Etc.
It widely used for liquid filling in cups ,the cups can be different kinds of plastic cups with different shapes , such as roundest, peach, panda hearts vs. of pure water ,mineral water ,fruit juice etc .
The measuring system is piston pump ,With high precision .
|
|
|||
Capacity |
3200-3600pc/h |
4500-5000pc/h |
6000-7000pc/h |
8000-9000pc/h |
Motor power |
750W |
750W |
1.5kw |
1.5kw |
Total power |
4kw |
6kw |
8kw |
10kw |
Voltage |
AC380V/50HZ |
AC380V/50HZ |
AC380V/50HZ |
AC380V/50HZ |
Weight |
600kg |
900kg |
1200kg |
1400kg |
Dimension |
3500*870*1600(mm) |
3500*970*1600(mm) |
4000*870*1600(mm) |
4000*1090*1600(mm) |
Pressure |
0.65-0.85MPa |
|
||
Gas consumption |
0.4m3/S |
0.6m3/S |
0.7m3/S |
0.8m3/S |
Alnajem group keeps 100% confident and try our best ability to satisfy customers' requirements with their selected products. Additionally, Alnajem group owns a professional aftersale customer service team. Therefore, If you have any inquiries or questions, have a look other products and leave your message. Your message will be highly appreciated! Welcome to Alnajem group
