Fully Automatic Cup Forming Sealing Machine

Fully Automatic Cup Forming Sealing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Other, Beverage, Machinery & Hardware
Packaging Type:
Other, cups
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Guaghzhou/Shenzen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage, Other, Beverage, Machinery & Hardware
Packaging Type Other, cups
Packaging Material Paper, Plastic
Automatic Grade Other, fully automatic
Driven Type Electric
Voltage 220V/380V
Power 18 kw
Place of Origin Guangdong, China
Brand Name AL-Najem
Model Number DGD
Dimension(L*W*H) 9300*3750*4000
Certification CE&ISO
After-sales Service Provided Engineers available to service machinery overseas

fully automatic cup forming sealing machine







the main features



the DGD series machines are applicable to the packaging production of yogurt , milk beverage. seasoning etc. with the function of accomplishing paper cup or plastic cup loading filling lid placing sealing date printing covering and product transportation full-automatically . these are equipped with world famous top brands system. this series machine which have the optional systems of 100-class laminar flow protection fruit particle and essence dynamic mixture, high- temperature filling and mobile code printed . Are the first choice for high- efficiency , energy saving and fully - automatic production



Technical Parameter:



Model

DGD600F

DGD300F

DGD200F

DGD100F

Output

200c/h (150ml)

10000c/h (150ml)

6600c/h (150ml)

3000c/h (150ml)

Operation Mode

Linear step

Rotary step

Preformed CupType

Plastic cup , paper cup

Lid Type

Precut lid, Rolling film

Total Power

18 kw

9 kw

7kw

4.5kw

Operation Power

10kw

5kw

4kw

2.2kw

Working Air pressure

0.7Mpa

0.7Mpa

0.7Mpa

0.7Mpa

Air Consumption

1.5 3m/min

1.1 3m/min

0.9 3m/min

0.5 3m/min

Overall Dimension

9300*3750*4000

4200*3000*2880

4200*2900*2880

2900*2100*2750

Weight Approx

6t

3.2t

2.6t

1.8t



Alnajem group keeps 100% confident and try our best ability to satisfy customers' requirements with their selected products. Additionally, Alnajem group owns a professional aftersale customer service team. Therefore, If you have any inquiries or questions, have a look other products and leave your message. Your message will be highly appreciated! Welcome to Alnajem group





fully automatic cup forming sealing machine

fully automatic cup forming sealing machinefully automatic cup forming sealing machine
