powder making machine

The solution, emulsion, suspension liquid or slurry are sprayed into fine beads in the hot air, going down from the top of the drying chamber to the bottom, the water will be evaporated to and the product becomes small granular product.

Food Industry: whole milk powder, skimmed milk powder, cocoa milk powder, milk substitute, egg white (yolk), etc. armpit prion, Oats, chicken juice, instant tea, seasoning meat, protein, soybean, peanut protein, protein thydrolyzate. Corn syrup, corn starch, glucose, pectin, maltose, potassium sorbate, pumpkin powder, instant coffee, and non-dairy creamer etc.

Pharmaceutical products: Chinese traditional medicine extract (herb extract), medicine colloid, yeast, vitamins, antibiotics, amylase, lipase, etc.

Plastics resin: AB, ABS emulsion, urea-formaldehyde resin, phenolic resin, dense plastic (urea) formaldehyde resin, polyethylene, polyvinyl chloride, etc.

Detergent: advanced washing powder, normal washing powder, soap powder, soda powder, emulsifiers, brighteners, phosphoric acid agents.

Chemical Industry: Sodium fluoride (potassium), alkaline dyestuff and pigment, dye intermediates, Mn₃O₄, formic silica acid, catalyst, sulfuric acid agent, amino acids, silica, etc..

Ceramic: aluminum oxide, ceramic tile material, magnesium oxide, talc, etc.

The designs of our spray dryer are advanced in China, as well as worldwide. If we compare the important parameters of our spray dryers and some famous brand in the world, such as final moisture content, color, flavor, particle size, solubility and bulk density etc, they are very close, or sometimes, ours are even a little better. A lot of customers have achieved their desired results with our equipment.

Notes for Inquiry:
1. Liquid material name and physical properties: solid contents (or moisture contents), viscosity, surface tension, PH value, etc. If there’s any other liquid, such as organic solvent, please specify the name and percentage clearly.
2. Product characteristics: final moisture content required, the range of particle size, and heat sensitive temperature etc.
3. Special requirements (if any): range of specific bulk density, color, and flavor etc.
4. Working capacity (kg/h or ton/h). If the capacity is based on per day, per month or per, please also indicate the working hours.

5. Heat source: it could be the pressure of steam, electricity, coal, oil, natural gas, LPG and other combustible materials.
6. Control requirements: the way to control the air inlet temperature, liquid supply system, pneumatic hammer etc, and the type of the system control (normal push button type, PLC+HMI, and PC system etc)

7. Fines collection type: depending on the product characters and environment protection requirements, we have following options, cyclone, bag filter, wet scrubber and their combinations.

8. Other special requirements: dimensions of the workshop, height limit and special electricity requirements etc.

Note:Customers might provide part of the above mentioned aspects. Other requirements, we should decide after making trials, or after technical discussion with the customer, or as per our experience

Remarks:

1. Nominal water evaporation capacity: It is calculated according to the inlet air temperature of 350°C, and the exhaust air temperature of 85-90°C.
2. Standard specification: The specifications listed above are named based on nominal water evaporation capacity.
3. Process specifications: For specific equipment, we normally name the equipment as per the specific processing parameters and requirements.
For the products which heat sensitive temperature is more than 110°C, the process specifications is about the same with the standard specifications.
For most food or the other products which heat sensitive temperature is normally low, the process specifications are about equivalent to 2-3 times of the standard specifications. Such as YPG2000 for drying food, the drying tower is about equivalent to the standard one of YPG4000 or of YPG6000 (vary as per the properties of the product).
For the products with high heat sensitive temperature, the inlet air temperature could be up to 450°C or even higher, the process specification is smaller than the standard specifications. But the requirements of the drying tower and relative configurations should be higher if the air inlet temperature is more than 450°C
4. Product yield: We provide a variety of fines collection and product recovery devices as per customer requirements and product characteristics, so to ensure it meets customer requirements.

5. Test: We have the most advanced trial facilities in China to make trials for the customers, so to ensure that the equipment reaches the customer requirements in the contract.
6. Configuration: Please refer to the flowcharts and instructions
7. Advanced design: we are considering the customer’s requirements, low investment, low running cost and energy saving when we make a design. If we compare our machines and some other machines, the special feature is that our machine is design for energy saving. For the medium and large specification equipment, the thermal efficiency of our design is normally around 37 - 50%, i.e., around 2.0-2.7kg of steam to evaporate 1 Kg water
