Home > Industrial Equipment & Components > Welding & Soldering Supplies > Welding Wire > China Factory Mig Cored Welding Wire Co2 Welding Wire

China Factory Mig Cored Welding Wire Co2 Welding Wire

China Factory Mig Cored Welding Wire Co2 Welding Wire photo-1
China Factory Mig Cored Welding Wire Co2 Welding Wire photo-2
China Factory Mig Cored Welding Wire Co2 Welding Wire photo-3
China Factory Mig Cored Welding Wire Co2 Welding Wire photo-4
China Factory Mig Cored Welding Wire Co2 Welding Wire photo-5
China Factory Mig Cored Welding Wire Co2 Welding Wire photo-6
US$ 500 - 2,000 MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Tianjin, China
Brand Name:
X & Z Flux cored welding wire Co2 wire
Model Number:
AWS A5.20 E71T-1
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG CHINA
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Tianjin, China
Brand Name X & Z Flux cored welding wire Co2 wire
Model Number AWS A5.20 E71T-1
Material Other, Low carbon steel
Diameter 0.8mm 0.9mm 1.0mm 1.2mm 1.6mm
Melting Point standard
Weight 15kgs/spool
Application Mainly used for welding low carbon alloy steel, widely used in industr
Flux Content standard

China factory mig cored welding wire Co2 welding wire

China factory mig cored welding wire Co2 welding wireChina factory mig cored welding wire Co2 welding wire



Product Description

Co2 welding wire

Specification

Flux cored welding wire is suitable for all-position welding

Flux cored welding wire

1. Size.:0.8MM, 1.0MM,1.2MM,1.6MM

2. Advantages :excellent welding performance, soft and stable arc, low spatter loss, easy slag removable, higher deposition rate particularly and suitable for all -position welding.

3. Typical application: Metallurgical industry, Bridge building, building industry, shipping industry

4. packing: 15kg/spool (paper box packing) 72 boxes/pallet(1080kg), 23760kg (22pallets), loaded in one 20 feet container

5. Quality certificate: ABS, LR, BV, GL, DNV, KR, CCS .

6.Chemica l Composition and technical data



Chemical Component of Final Production(%)

Component

C

Si

Mn

P

S

Cr

Ni

Cu

Standard

Max.0.12

Max.0.9

Max.1.75

Max.0.030

Max.0.030

Max.0.20

Max.0.50

Max.0.35

Typical Test of Mechanical Property

Yield Strength

σ0.2(MPa)

Tensile Strength

σb(MPa)

Percentage Elongation

δ5(%)

impact value

(J)

Test Temperature

(°C)



535

         639

25

112

-20



























China factory mig cored welding wire Co2 welding wire



Application

China factory mig cored welding wire Co2 welding wire

China factory mig cored welding wire Co2 welding wire



Flux cored welding wire

Used for welding structures made of carbon steel and low-alloy structural steel with tensile strength higher than  or equal to 490MPa. Most widely used for welding some key structures like shipbuilding, mechanical manufacture, pressure vessels, boilers, petroleum machinery, chemical machinery, hoisting machinery, etc.

Packaging & Shipping

Co2 welding wire

China factory mig cored welding wire Co2 welding wire

 Packaging Details of flux cored welding wire E71T-1

15kgs/spool, one spool into a carton

72 cartons per pallet

Our Services

Co2 welding wire

China factory mig cored welding wire Co2 welding wire

Xuzhi company was founded in 1998. After years of development, now the company already had the mainstream business which shows in the next item.

Except the mother company “xuzhi company”, we have other companies were built according to professional led division, intensive management framework. At present the company development direction is to professional industry chain deep direction. Thus be dedicated to research and development, design, manufacture industry professional technology of highly sophisticated products.



Company Information

Co2 welding wire
China factory mig cored welding wire Co2 welding wire

Xuzhi company product scope:

(1)   Flux cored wire plant project Consulting (including the new factory process design, old factories technology and equipment reform, improve the production efficiency, the new product formula design and development.)
(2)
Flux cored wire complete line manufacturing
(3)   Hardfacing & stainless steel etc special flux cored wire product manufacture
(4)   Provide high quality2roll-type and 3roll-type of roller die cassette for the following types of customers:
1)
flux cored wire manufacturer
2)
solid wire manufacturer
3)     rebar manufacturer
4)     Metal products related company, such as: nail making, welding nets, wire rope, reinforcement wire, Electric wire and cable, non-ferrous metal products, etc.)
(5)   Produce various specifications and types of wire drawing machines used in metal products processing and manufacturing
(6)   Metal products finished product cleaning machine (such as: steel strip cleaning, machinery parts cleaning, glasses cleaning, and more complex shape metal products finished product cleaning)
(7)   Metal products auxiliary machine manufacturing (such as: various types of pointing machine)
(8)   Food machinery and pharmaceutical machinery manufacturing

Co2 welding wire











Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
Business Type
Manufacturer, Trading Company
Year Established
1998
Factory Size
3,000-5,000 square meters
Total Employees
51 - 100 People
