welding wire kobelco brands oerlikon welding electrodes
- 100000 Ton / Tons per Month
- xingang tianjin china
- T/T Credit Card
Product Details
Place of Origin: | Tianjin, China | Brand Name: | oerlikon welding electrodes | Model Number: | oerlikon welding electrodes |
Material: | Steel Alloy | Length: | 300-450mm | Operating Current: | 90-250A |
Welding Current: | 90-250A, 60-90, 90-120, 120-150 | Operating Temperature: | 20-40C | Diameter: | 2.5-5.0mm |
Application: | welding low-carbon steel structures |
Product Description
oerlikon welding electrodes
oerlikon welding electrodes show details
Notes on Usage:
oerlikon welding electrodes
1. Dry the electrodes at 70~100 (158~212 ) for 30~60 minutes before use.
2. Pay attention not to exceed the range of proper currents.
Chemical Composition | C | Mn | Si | S | P |
Guarantee Value | ≤0.12 | 0.3-0.6 | ≤0.35 | ≤0.035 | ≤0.040 |
Mechanical Properties of Deposited Metal
Test Item | Rm(MPa) | ReL(Mpa) | A(%) | KV2(J) | KV2(J) |
Guarantee Value | ≥420 | ≥330 | ≥17 | -(normal temperature) | -(0℃) |
Reference Current (AC, DC)
Electrode Diameter(mm) | φ2.0 | φ2.5 | φ3.2 | φ4.0 | φ5.0 |
Length(mm) | 300 | 300(350) | 350 | 400 | 400 |
Welding Current (A) | 40~70 | 55~95 | 80~130 | 120~180 | 160~230 |
V-up, OH | 35~60 | 45~90 | 60~120 | 100~160 | 120~200 |
Produce Procedure: Wire Drawing--Wire Cutting
oerlikon welding electrodes
Produce Procedure: Coating—Drying
oerlikon welding electrodes
Advantages:
1. Stable arc, less splash
2. Shaped good appearance
3. Easy for removal of slag layer
4. Easy for striking arc and restriking arc
5. Operable with low amperages on sheet metal
6. Slag control accommodates vertical down welding
oerlikon welding electrodes
Usually one 20ft container can load 1250 cartons, 25 MT. If the shipping line agrees, it can be
loaded into 1350 cartons, 27 MT. One MT is about 0.6 CBM, one carton is 20kg.
Usually the package is following:
Size: 2.5mm*300mm,
package: 2.5 kg/inner box, 8 boxes/ carton=20kg,
Size: 3.2mm*350mm,
package: 5.0 kg/inner box, 4 boxes/ carton=20kg,
Size: 4.0mm*400mm,
package:5.0 kg/inner box, 4 boxes/ carton=20kg.
Inner box is a shrink-wrapped cardboard box.
Moreover, we can do it on pallets as client’s request: 1MT/Wood Pallet or 2.5MT/ Iron Pallet.
oerlikon welding electrodes
We mainly produce and deal with the products as follows:
Carbon Steel Welding Electrode AWS E6010, E6011, E6012, E6013, E7014, E7015, E7016,
E7018 and E7024, Stainless Steel Welding Electrode E308L-16, E309L-16, E316L-16,
Cast Iron Electrode. We can satisfy the customers’ need according to each national electric
voltage standard.
2.0*300mm, 2.5*300mm,
2.5*350mm, 3.2*350mm,
4.0*400mm, 5.0*400mm.
oerlikon welding electrodes Warehouse
We have a large stock for welding rod, short delivery time.
oerlikon welding electrodes
1.Professional service for products
2.Much more competitive price
3.Honest and excellent supplier
4.Delivery time is shorter than others.
5.We believe the good quality is the basis for cooperation.
6.We could provide free samples for test to you.
7.Our company policy is Quality First, and to establish Long Time business, not just one time.
oerlikon welding electrodes
1. Are samples available?
Answer: We are happy to provide free samples to you after you accept our quotation and really want to cooperate with us.
2. Is OEM available?
Answer: Yes, because we usually do it like that.
3. What is your company normal payment terms?
Answer: Usually we accept T/T, 30% T/T prepaid before production, 70% T/T payment after you see the copy of B/L. If you are one real buyer, we also can accept L/C at sight.
4.What are your company normal export terms?
Answer: We normal export with CFR, CIF and FOB trade terms.
5.How many days it will take you to produce mass production for us?
Answer: Usually it takes about 7-15 days, it also depends on the quantity and production seasons.
Looking forward to cooperating with you!
