Help CenterWater Truck
Related Products
Specifications
Water truck adopted for carrier;DONGFENG CUMMINS EQB160-20 engine of 160 horsepower can meet Europe 2Water truck
New model DONGFENG EQ1108G6DJ15 chassis is adopted for carrier;DONGFENG CUMMINS EQB160-20 engine of 160 horsepower can meet Europe standard for good environment; The emission, noise and safety all meet the national standard.
·The machine is equipped with hydraulic power shift devoice and easy for operation.
·The driver cab is made in a Japanese technique, with beauty shape, comfortable seat and wide-view for modern feeling.
·The truck is equipped with Good air conditioner system
·The water flushing truck is installed of high-pressure ram-pump with a flow rate at 160L/min, rated pressure at 15Mpa. This kind pump is the most advanced product in our company in a whole Germany technique of KAMAT company since 2001,which remains high performance working and certain pressure for long time; Adopted for the high pressure power devoice with the dual insurance system of overflow valve and safe valve. The capacity of dredging reach up to the advance lever in and abroad.
·The control system form combining pneumatic control and electric control for easy operation and safety, priority to the other product in China.
| Model of the truck carrier | EQ1108G6DJ15 |
| Max power | 118/2600kw/r/min |
| Max torque | 559/1600N.m/min |
| Model of high pump | 3NS |
| Rated pressure | 15Mpa |
| Flow rate | 160L/min |
| Engine model/company |
EQB160-20/Dongfeng Cummins engine with air conditioner |
| Hose winding speed | 15m/min |
| Hose winding force | 2000N |
| Hole included angle | 15°/25° |
| Thrust | 190-120N |
| Inside diameter of hose | φ19mm |
| Type of hose coupling | C |
| Length of hose | 80m |
| Water tank capacity | 6m3 |
| Overall dimensions(LWH) | 8350*2462*2690 |
