SS304 Square High Shear Emulsification Tank

Square High Shear Emulsification Tank

Feature

• There are 600L~5000L varietys of specifications, it can be designed, customized according to the customers' requirements.

•Connector use fast installation chuck  (clamp), inner tank use SS304 or SS316L, the inner surface mirror polishing Ra≤0.28μm~0.6μm, outer surface can be polishing, wiredrawing ,sandblasting according to customer's requirement.

•Square High Shear Emulsification Tank use mechanical emulsification at bottom, adopt claw type occlusion, double suck material structure; high speed mixing and emulsification, can be suitable for different mixture, mixing, dispersion, emulsification, homogenization.

• Emulsification shaft seal use sanitary mechanical seal, emulsification motor can use planet-cycloid retarder, stepless reducer according to the customers' requirements .

Application:

•Suitable for food (milk), beverage,  biotechnology, pharmaceutical, fine chemicals, pigment etc .  mixed liquid and mixture in the tank is full and rapid mixing, dispersion, emulsification, homogenization.

Jhen Ten carries on traditional Japanese production skills and latest Japanese industrial technology to produce filtration products and all kinds process machinery .
In addition to the introduction of new manufacturing methods and the purchase of advanced welding equipment, we are also dedicated to researching the improvement of quality, function and usage life of our products. We have been meeting global demand of high quality &technical support to our clients.Our products cover from all kinds sanitary filter,cartridge filter, bag filter ,mixing tank ,storage tank etc,which have been applied into fields of pharmacy, food & beverage, biological engineering, lab solution laboratories, mineral water, liquor and cosmetics.

No matter the functions, data presentation, material use, welding techniques, QC, or the look of our products have gone through careful design and are strictly comply with ISO9001 and CE standard system.Besides We have obtained the sanitary license and honour of high quality&honesty from authority.
