Home > Products > Processings line > bottled water processing line fruit drink Mike processing line
bottled water processing line fruit drink Mike processing line
- 1 Set / Sets per Month
- QINGDAO PORT
- T/T D/P D/A
Product Details
Place of Origin: | Shandong, China | Brand Name: | GS Pak, GS Pak | ||
Model Number: | - | Type: | Other, - | Voltage: | - |
Power(W): | - | Weight: | - | Dimension(L*W*H): | - |
Certification: | SGS | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
bottled water processing line fruit drink Mike processing line
Main imported elements of the Processing Line |
Equipment Name | Melt machine |
Equipment Type | RLJ-1000 |
Kind of beverage | Milk/ Juice/beverage |
Effective volume | 1000L |
Heat preservation layer | 50mm |
Inlet diameter | φ38 |
Outlet diameter | φ51 |
Motor power | 15kw |
Outline dimensions | 1200×1500×1500mm |
Equipment Name | Material pump |
Equipment Type | B1-20-25G |
Kind of beverage | Milk/ Juice/beverage |
Impeller diameter(mm) | 150 |
Motor power(kw) | 3.0kw |
Lift(m) | 25m |
Medium | 20°C(cleam water) |
Rotation speed | 2905r/min |
Flow | 20m³/h |
Inlet diameter | φ51mm |
Outlet diameter | φ51mm |
Equipment Name | Blend tank |
Equipment Type | TPG-3000 |
Kind of beverage | Milk/ Juice/beverage |
Effective volume | 3000L |
Diameter of inlet&outlet | φ38/φ51 |
Heat preservation layer | 50mm |
Motor power | 2.2kw |
Product Description |
Mechanical Details |
Main imported elements of the machine |
No. | Name | Supplier | Origin |
1 | PLC | Mitsubishi | Japan |
2 | Touching screen | PWS6A00T-P | Japan |
3 | Electricity switch | MOELLER | French |
4 | Control valve | BURKERT | Germany |
5 | Color meter sensor | SICK | Germany |
6 | dynamo | ABB | Sweden |
7 | Water pump | CALPEDA | Italy |
8 | Pneumatic control parts | FESTO,CAMOZZI | Germany |
9 | XMTG | OMRON | Japan |
Our Servvices |
Overall Plan
According to customer's willingness,design the best overall plan which not only
meets the technological requirements ,but also match with investment program.
Turn-key purchase reduces the procurement cost
Reduce the unit price of your procurement cost
Reduce the logistics cost
Reduce your human and communication cost
Avoid repeated investment cost
Turn-key purchase will be realized by BIHAI'S Supply Department.
Turnkey project
No worried about the crossover consturuction
Make sure the installation working more smoothly
Provide the unified after-sales service
Offer the whole operation guide to you
Professional turnkey project,Bihai engineering department do that for you.
Any problem,BIHAI will help you in the whole process to solve them
BIHAI's Training team will guide and enable your staffs to operate and carry out maintenance
BIHAI's After-sale Team will hepl you to solve all kinds of equipment failures.
BIHAI's quality control will help you to solve all kinds of quality problems
To solve all kinds of production problems,BIHAI's After-sale Department will do it for you.
