Aseptic Filling Machine

Aseptic Filling Machine thumbnail-1
Aseptic Filling Machine photo-1
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, milk, beverage, juice, tea, soya-bean milk
Packaging Type:
Cartons
Contact Supplier Request Quote Chat Now
Shandong Bihai Packaging Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, milk, beverage, juice, tea, soya-bean milk
Packaging Type Cartons
Packaging Material Other, laminated paper
Automatic Grade Automatic
Driven Type Electric
Power 35KW
Place of Origin Shandong, China
Brand Name Bihai
Model Number BH-3600

Specifications

Packaging Speed: 3600cartons/h
Types: One produces 250mlB; another 250mlS
MILK, JUICE,VEGETABLE PROTEIN DRINKS allowable

Aseptic filling machine for juice or milk:

BH7500: 6000 cartons/h for 250ml base and slim.

BHW3600: 3600 cartons/h for 250ml, 200ml base and slim.

1. Type                    BH-3600

2. Name                  Aseptic carton filling machine

3. Capacity             3600pcs/h

4. Volume                250±5ml

5. Dimension          4800mmx3100mmx3600mm

6. Entrance gate      2200mm(W)X3800mm(H)

7. Weight                  3500kg

8. Power                   380V±10% (Ø3)50/60Hz

9. Power usage amount         20KW

10. Compressed air consumption        0.9 M3/min

11. Purified water amount      8L/min (0.3~0.45Mpa, 20°C below)

12. Steam amount                2.5kg/h (130±5°C, 0.17±0.03Mpa)

13. H2O2 amount                 0.3~0.6L/h(density at 30~50%)

14. Operating system           HM5

15. Printing equipment         Inkjet printer

16. Conveyer belt                  Keel chain

17. Product temperature     15°C~25°C

18. Product Viscosity           30CP below

19. Product density              2-3%

20. Type of connection and caliber     thread entrance, 1/2

21. Connecting pressure                50~150±10KPa62

23 Container spec(H×W×L)           106.3×41×63mm(250mlbase)

24. Form of packaging materials      Roll

25. Temperature of the plant             15~35°C

26. Hydraulic oil,lubricating oil          Please use required type.

27. Cooling water should be purified water

28. Type of transportation  the machine is packed with wooden box via trucks or ships

29. Work environment : Operating temperature:5-32°C    Work noise:63-75db  Humidity   20-60%rh

30. Life span: production time over 150 thousand hours.

31. On concrete level ground

32. CIP is needed after 20 hours continuous operation, and when the operation is disturbed in less than 20 hours, please perform CIP after the stop.
