Horizontal Milk Cooling Tank 5000L Cooling Tank

Name: Horizontal Milk Cooling Tank 5000L Cooling Tank
Brand: WANYUAN
SKU: 141367922
Availability: InStock

US$ 2,170 - 20,202 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

WANYUAN

Wenzhou Longwan Wan Yuan Food Machinery Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name WANYUAN

Model Number 300L--20000L

Processing Types Milk

horizontal cooling tank for milk

5000Liter Horizontal milk cooling tank

Wanyuan Efficient Milk Cooling Tank:

Horizontal milk cooling tank 5000Liter cooling tank

milk cooling tank Information:

This machine is adopting internationally-advanced technology of the 1900s. It cools by circular and vertical wall. The full automatic control system makes whole process of preservation avaiable. The cooled raw milk can reachrapidly needed temperature of 4-5^oC and keeps constant,which can prevent the generation of bacteria and make raw milk as agrade cream.
The adopted imported compressor features high performance,energysaving,full seal and protection system that prevents damage due to overload.also fitted are high& low liquid level control system and automatic cyclespray and agitating device.
2.The temperature preservation lay adopts the craft of urethane blowup featuring excellent heat insulation it is an ideal store and cool equipment to milk collection sation,meadow and unit which specializes in farming milch cow.

Horizontal milk cooling tank main Parts:

5000Liter Horizontal milk cooling tank Main Technical Prameter:

Volume (L)	300	500	1000	2000	25000	3000	4000	5000	10000
Average Cooling Capacity(kcal./h)	4000	4400	6600	11000	14000	16200	22000	26400	44000
Refrigerant	F22
Injecting Refrigerant Amount (kg)	1.5	2	3	6	7	8	12	14	20
Mixer Speed (r/min)	35	35	35	35	35	35	35	35	35
Total Power (KW)	2.4	2.52	3.53	5.81	5.0	6.6	11	11.6	17.2
Electrical Source	3-380V-50HZ
