Electric Jacketed Kettle Tomato Sauce Cooking Kettle

Electric Jacketed Kettle Tomato Sauce Cooking Kettle thumbnail-1
Electric Jacketed Kettle Tomato Sauce Cooking Kettle photo-1
US$ 800 - 3,600 MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
wanyuan
Contact Supplier Request Quote Chat Now
Wenzhou Longwan Wan Yuan Food Machinery Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name wanyuan
Model Number jacketed kettle 300L
Processing Types tomato paste
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

200L electric heating jacketed kettle with scraper

agitator kettle mixing kettle cooking kettle
this is a 300L gas heating tilting jacketed kettle with mixer agitator



we offer different kind of jacketed kettle

1. steam heating cooking kettle

2. gas heating jacketed cooker

3. electric heating cooking pot



here are the the specifications of the kettle wenzhou wanyuan offers:





MODEL

INTERNAL DIAMETER

BLENDING POWER

ELECTRICAL SOURCE

BRAND

50L

600mm

0.55kw

380V,50Hz

WANYUAN

100L

700mm

0.75kw

380V,50Hz

WANYUAN

200L

800mm

0.75kw

380V,50Hz

WANYUAN

300L

900mm

0.75kw

380V,50Hz

WANYUAN

400L

1000mm

1.1kw

380V,50Hz

WANYUAN

500L

1100mm

1.1kw

380V,50Hz

WANYUAN

600L

1200mm

1.1kw

380V,50Hz

WANYUAN

700L

1250mm

1.1kw

380v, 50Hz

WANYUAN

800L

1300mm

1.1kw

380v, 50Hz

WANYUAN







Jacketed kettle catalogue

Jacketed kettles are used to cook or concentrate products. Heat enters a jacket that surrounds the bowl-shaped processing chamber, and being transferred through the walls of the jacket. It is also called jacketed pan, or jacketed pot, also, you can call it as a cooking pan, or cooking kettle. "Cooking" kettles are found in many industries, including meat packing, rendering, paper making, sugar processing, and food preparation and processing.

Three types of kettles are in common use.

  1. Steam heating jacketed kettle




  1. Electric heating jacketed kettle

  1. Gas heating jacketed kettle


CHARACTERISTIC

  • Bothe the above listed jacketed kettles can be tilting type or vertical type
  • Agitator can be customized, with an agitator or not is up to you
  • If needed, we can add scrapers to the agitator to avoid your material get burned
  • All the kettles equipped with digital temperature system
  • Capacity can from 50Liter to 1000Liter
  • Material can be SS304 or SS316 as needed.



Jacketed kettle sketch for reference

Steam heating jacketed kettle sketch



Electric heating jacketed kettle sketch



Gas heating jacketed kettle sketch



Meaning of symbol

No.

Symbol

Meaning

Connection type

1

A-1 / A-2

Condensed water interface

²  Thread

²  Clamp

²  Union

²  Hose coupler

²  1/2”, 3/4”, 1”, 1 1/2”…..

2

B-1 / B-2

Steam Interface

3

C-1 / C-2 / C-3

Exhaust port

4

D

Gas / LGP inlet

5

E

Gas burner

6

F

Material discharge

In order to offer you a reasonable price, please let us know your detail request on the kettles as below:

                                     Steam heating                                         with agitator

We need     (quantity)    Electric heating   tilting  jacketed kettle

                                     Gas heatingvertical                                  without agitator

Other request:

         1.

         2.

         3.





For example:

                                  Steam heating √ tilting                                with agitator √

We need  6 (quantity) Electric heating                jacketed kettle

                                 Gas heatingvertical √                                  without agitator



This mean: you need 6pcs steam heating tilting jacketed kettle with agitator

Other request:

Kettle material should be SS304, no need scrapers because the cooking materials are not sticky.











  small capacity electric heating jacketed kettle with agitator
