keyworkds" mixing tank, heating mixing tank, electric heating mixing tank
electric heating mixing tank
1. stainless steel mixing tanks with agitator mixer
2. steam heating mixng tank
3. jacketed mixing tank with inverter
4. Stainless steel tankwith agitator,
5. heating and cooling, PLC control stainless steel suger syrup mixing tank
introduction for wanyuan stainlsees steel mixing tank
mixing tank for syrup-stainlsee steel mixng tank with agitator
For dairy product, beverage, medicine, cosmetics, washing liquid…
1500L jacketed mixing tank with steam heating jacket Stainless Steel Tanks
Our stainless steel tanks are fabricated to order allowing for complete customization for your application. However don't expect to wait 12-14 weeks for your stainless steel mixing tank. Wanyuan food through a pre-engineering process, can deliver your tank in less than half that time. Just submit your specifications, and we can modify a standard stainless steel tank design, get you a drawing to approve, you sign it and away we go. Standard tanks drain through the bottom mount 2NPT half coupling. There are many options from 316SS construction and #4 polish, to mixer brackets, custom fittings, dimple jackets, and level gauges. If you are in urgent need of a stainless steel mixing tank, stainless steel storage tanks, stainless steel fermenters, stainless steel heating tanks or any other kind of stainless steel tank for food such as milk, juice, beer…, contact us freely!
Tank capacity | material | Diameter | Agitator | Temperature control |
300L | SS304 SUS316 Stainless steel | Φ700×1500 | 36rpm 100rpm 300rpm 100-1000rpm | PLC control Sami-automatic control |
500L | Φ800×1600 | |||
800L | Φ1000×2000 | |||
1000L | Φ1100×2200 | |||
2000L | Φ1400×2300 | |||
3000L | Φ1500×2400 | |||
5000L | Φ1800×3200 |
1000L jacketed mixing tank with steam <hot water>heating jacket
1000L jacketed mixing tank with steam <hot water>heating jacket
However, we don't just specialize in getting you a stainless steel tank fast, but give you options and ideas to improve your stainless steel mixing tank that you may have not considered. In over a decade of experience, designing thousands of stainless steel tanks with agitators or without, for hundreds of different industries, our engineering department can not only build what you specify, but can add the value of new solutions. Many can fabricate stainless steel mixing tanks, but very few can turn your tank challenge into an innovative success.
Stainless steel tank | Usage | Optional Function |
Single layer | Storage Insulated storage tank Cooling and heating tank Cold and Hot Urn 500L mixing tank Fermenter / pasteurizer | Level meter Thermometer Ladder Sampling valve Temperature PLC control frequencycontrol speedcontrollerwithinverter |
Double layer | ||
Three layer |
1000L jacketed mixing tank with steam <hot water>heating jacket
Heating or cooling your mixing tanks can be a constant struggle. Stainless steel tanks can require ASME certification at certain temperatures and pressures. If heating dead spots must be eliminated in your stainless steel tank, wanyuan has an innovative bottom dimple jacket that does just that with still one inlet and outlet on the tank. Our fiberglass insulation and stainless sheathing insure a spectacular finish and increased safety. Another challenge in stainless steel mixing tanks is applying the correct surface finish. Wenzhou wanyuan can work with you to find the right finish for your application. We can achieve something as precise as a single digit Ra finish with passivation and electro polish, to something as cost effective as a 2B mill finish and anything in between. Achieving the right surface finish is crucial to limit bacterial growth in biological applications and cleaning time in all applications.
Key words: bacteriological incubator, fermenters, mixing tanks, cooling and heating tanks
1. triple walled construction
2. inner made of SS316. mirror polished
3. outer made of SS304. dull finish
4. gap b/n the two walls filled with glass wool insulation of 50mm
5. heating element is made of SS "U" type tubular
nichrome wire with SS sheathing
6. heaters are placed at the right and left side of the inner chamber
7. PID controller with auto tuning facility with double display to view set and current temp.
8. temp. range 0-300 D.C. with accuracy of +/- 5 D.C.
9. Silicon rubber gasket fitted on manhole to prevent lost of heat.
1000L jacketed mixing tank with steam <hot water>heating jacket
