Fresh milk batch pasteurizer tank / fruit juce pasteurizer
batc pasteurization tank with agitator / heating tank with mixer
300L200L juice pasteurizaion tank
MAIN DATA SHEET OF MANUFACTURING & INSPECTION for pasteurizaion tank
Item | Inner tank | Jacket | Design date | ||
hydraulic test | full water test | 0.2 MPA | Item | Inner tank | Jacket |
1. Designed according to the relevant provisions of the food industry.
2. Meet safety operation system.
3. The inner tank should be hydraulically tested after fabrication
4. Hydraulically test of chloride ion must not be more than 25mg/L | Working pressure | Normal | Normal | ||
Design pressure | Normal | Normal | |||
Working temp | Normal | Normal | |||
Design temp | Normal | Normal | |||
Working medium | Material | Heating oil | |||
Material | SUS304 | SUS304 | |||
Capacity | 300L | ||||
Heating power | 18Kw (6kw×3pcs) | ||||
Agitator type | Frame agitator | ||||
Motor power | 0.75KW frequency control | ||||
Insulation | PURF | ||||
ORIFICE TABLE pasteurization tank with agitator / heating tank with mixer
No. | Nominal size | Connection type | Usage |
N1 | Φ 38 | Quick install | Material inlet |
N2 | 32 | Thread | Heating oil inlet |
N3 | 32 | Thread | Heating oil outlet |
N4 | Φ 50 | Quick install | Material outlet |
T1 | M27 | Thread | Temperature gauge |
T | M27 | Thread | Temperature sensor |
