Stainless Steel Mixing Tank With Steam Heating Jacket
US$ 2,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
WANYUAN
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2000L Sugar Melting Tank Sugar Dissolving TankUS$ 1 - 8,000MOQ: 1 Set -
500L Single Layer Mixing Tank Stainless Steel Mixing Tank for JuiceUS$ 1 - 8,000MOQ: 1 Set
-
Sugar Melting Tank Sugar Dissolving TankUS$ 1 - 8,000MOQ: 1 Set
-
1000L Mixing Tank for Juice MixingUS$ 1 - 5,000MOQ: 1 Set
-
Stainless Steel Milk Storage Tank Transport Milk TankUS$ 1,500 - 8,000MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
WANYUAN
Model Number
300L--10000L
Processing Types
Other, juice&milk
Certification
CE Certificate, ISO9001:2008
Warranty
One Year
After-sales Service Provided
Engineers available to service machinery overseas
offer stainless steel mixing tank with steam heating jacket
Seed tank,mixing tank,storage tank,,Bulk Mixing Storage Tanks
Usage:
used to caltivate the yogurt working hametz.apply to food,dairy ,juice,beverage,medicine,chemical.and biological engineering,etc
1.material is sanitation stainless steel.
2.structure design is extremely humanizaionlity is strong.
3.the barrel body wall using arc transition section,sanitation without blind angle.
tanks configuration:
1.asepsis respirator
2.the thermometor
3.CIP CLEANER
4.seed inlet
5.adjustable triangle feet.
6.mixer
7.jackted layer (according to the custom request to choose miller board or hollow jacketed.
8.lamp glasses
9.sampling valve.
Product Display
| mixing tank Product Name: | High quality mixing tank stainless steel mixing tank with agitator |
| mixing tank Description: | Designed according to 3A standard, widely used for transfer viscous media in the food-processing, cosemtics and pharmaceutical industries |
| Heating mothed for mixing tank |
By electricity (oils or water), by steam, by gas optional |
| mixing tank construction Material: | SS304 / SS316 |
| jacket: dimple jacket / hollow jacket / spiral coil jacket | |
| insulation layer: PU / rook wool / glass wool | |
|
mixing tank thickness customized mixing tank heating type customized | |
| stainless steel mixing tank Configuration | 1.manhole on top of mixing tank |
|
2.CIP spraying ball fixed on top of mixing tank <inner side of the mixing tank> | |
| 3.adjusting feet for mixing tank | |
| 4.sample valve for mixing tank | |
| 5.temperature gauge for mixing tank inner content | |
| ure gauge for mixing tank jacket | |
| 7.level gauge | |
| mixing Capacity: | 50L-10000L customized |
| mixing tank Agitator Type: | With / without scraper, paddle / impeller |
| Mechanical seal: | SIC/SiC/EPDM(Standard) |
| mixing tank Agitator power: | 0.55kw, 1.1kw, 1.5kw, 2.2kw, 3kw, …7.5KW |
| Sealing option: | Sanitary single mechanical seal/Double mechanical seal with cooling system |
| Voltage: | 220V, 380V,415V |
| Motor: | ABB, LOCAL,50hz/ 60hz |
| Surface treatment: | Inner polished and outside polished |
| Availably connection: | Clamp, Thread Butt weld, Flange |
| Availably standard: | DIN, SMS, 3A, RJT, ISO/IDF |
| Operated: | Electic |
| Application scope: | Dairy, food, beverage, pharmacy, cosmetic, etc |
| Packaging Details: | Plywood case or customerized. Or as per the request of customers |
| Delivery details: | Usually within 20 days after receiving T/T down payment |
| Food Industry | Yogurt, Ice Cream, Cheese, Soft Drink, Fruit Jelly, Ketchup, Oil, Syrup, Chocolate etc. |
| Daily Chemicals | Facial Foam, Hair Gel, Hair Dyes, Toothpaste, Shampoo, Shoe Polish, Cosmestics etc. |
| Pharmacy | Nutrition Liquid, Chinese Traditional Patent Medicine, Medicine Grease, Biological Products etc. |
| Chemical Industry | Fat, Dissolvent, Resin, Paint, Pigment, Oil Agent etc. |
| Other Industry | Contruction Industry, Plastic Industry, Textile Industry, Coal Floatation Agent etc. |
stainless steel mixing tank with steam heating jacket mixing tank price
