1000L Steam Heating Mixing Tank < With Dimple Jacketed Heating and Mixing Tank>

1000L Steam Heating Mixing Tank < With Dimple Jacketed Heating and Mixing Tank> thumbnail-1
1000L Steam Heating Mixing Tank < With Dimple Jacketed Heating and Mixing Tank> thumbnail-2
1000L Steam Heating Mixing Tank < With Dimple Jacketed Heating and Mixing Tank> photo-1
1000L Steam Heating Mixing Tank < With Dimple Jacketed Heating and Mixing Tank> photo-2
US$ 1 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
obama, Obama
Contact Supplier Request Quote Chat Now
Wenzhou Longwan Wan Yuan Food Machinery Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name obama, Obama
Processing Types Other, milk & juice
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

500L steam heating mixing tank with

heating mixing tank Usage

it is can used as storage tank,blending tank,registing tankcnn,and so on.apply to food ,dairy ,juice,beverage,medicine,chemcal.and biological engineering etc.



500L steam heating mixing tank with Charcateristic:

1.the inter barrel with outsourcing ,insulation layer is filled heat preservation material structure.

2.material is sanitation stainless steel.

3.structure design is extremely humanization,the maneuverability is strong.

4.the barrel body wall using arc transition section,sanitation without blind angle.



500L steam heating mixing tank with  tanks configuration:

1.quick open manhole

2.various shape CIP CLEANER.

3.prevent fly worm sanitation air masks.

4.adjustable triangle feet.

5.removable feeding inlet tube suite.

6.the themometer (according to the custom request)

7.the ladder (according to the custom request)

8.vertical mixer according the requirements of clents to choose blade of framc type

9.prevent eddy plate



500L steam heating mixing tank with  techincal parameter:



volume barrel size total height heat preservation layer inlet&outlet DN moter power mixing speed
L D*H  MM MM MM MM KW R/MIN
500 840*1000 2750 60 38 0.55 Common speed is 35,43,60,also can chose stepless speed reducer or double speed reducer
600 920*1000 2850 60 38 0.55
700 990*1000 2850 60 38 0.55
800 950*1000 3000 60 38 0.55
900 1010*1220 3000 60 38 0.55
1000 1060*1220 3150 60 51 0.75
1500 1160*1500 3350 60 51 0.75
2000 1340*1500 3410 60 51 1.1
3000 1410*2000 4000 60 51 1.5
4000 1620*2000 4250 60 51 1.5
5000 1810*200 4300 60 51 2.2
6000 1980*2000 4550 60 51 2.2
7000 1930*2440 5000 60 51 2.2
8000 2060*2440 5000 60 51 3
9000 2180*2440 5050 60 51 3
10000 2300*2440 5050 60 51 3
12000 2270*3000 5600 60 51 4
15000 2530*3000 5700 60 51 4
20000 2640*3660 6400 60 51 5.5

  500L steam heating mixing tank with
