The instruction of Reactor
Chemical React Equipment.
Is suitable for industrial mass production
Widely used in making resins, adhesives, paints, cosmetics, pharmaceuticals and other chemical productions
- heating, then engineer will design the mixing tank with jacekt with coil to meet the demand.
Equipped with distillation column, condenser, water separator, collecting cans, filters ect.
- Heated by oil, water, steam or electric.
Consists of body, gears, mixing devices, heating devices, cooling devices, seal composition.
- Our engineer designs various agitated reactor, like screw agitator, paddle agitator, disc agitator, anchor agitator etc.
Chemical Reactor can apply for
1). Resin
Alkyd resin, epoxy resin, phenolic resin, acrylic resin, ABS resin...
2). Glue/ Adhesive:
Hot melt glue/ adhesive, grafted/ neprene glue, white glue, silicone glue, all-purpose glue, PVC glue, PVA...
3). Others:
Paint, pigment, PVC, PVA, PVAC, PU, acrylic acid, and other latex, emulsion and liquid glue and adhesives.
The parameter of the chemical reactor:
We can also design other types for you as long as you require!
Type | Volume | Heating Mode | Structure | Paddles | Remarks |
FYF-100 | 115L | Electric heating Or Steam heating Or Water heating Or Oil heating | Jacketed
Or
Coil-pipe (inner & outer) |
Anchor & Ribbon paddles And also equipped with square blades. Also can equip with dispersing disk. | The motor of the reactor depends on the products’ viscosity.
The reactors are made of SS304 by default, but can be made of SS316 or Carbon steel also.
Heating mode can be chosen freely. |
FYF-200 | 220L | ||||
FYF-300 | 330L | ||||
FYF-500 | 535L | ||||
FYF-1000 | 1050L | ||||
FYF-2000 | 2080L | ||||
FYF-3000 | 3120L | ||||
FYF-4000 | 4120L | Oil heating Or Steam heating (Seldom use water and electricity heating) | |||
FYF-5000 | 5150L | ||||
FYF-6000 | 6150L | ||||
FYF-8000 | 8180L | ||||
FYF-10000 | 10200L | ||||
FYF-12000 | 12200L | ||||
FYF-20000 | 20200L | ||||
FYF-50000 | 50300L |
Reactor Production
Pictures:
With Limpe coil pipe jacket
1. Company introduction
1). Zhejiang Dafeng Light Machinery Co., Ltd. ( or )
2). Professional manufacturer for chemical machineries, with 17 years' rich experience in this field.
3). DF specializes in all kinds of reactors, mixers,dispersers and extractors etc. And the machines are widely used in all kinds of adhesives, resins, rubbers, paints, sealants, chemicals, emulsions and some food and pharmaceutical industries.
4). DF Machinery Co., Ltd was formally set up ten years ago, but the origianl entrepreneur team are all very professional engineers who were with 20 years' experience.
5). DF main markets: China, Europe, Africa, Middle East, South America and South Asia, we can sell machines to anywhere as long as it needs.
2.Certificate
1. Warranty and after-sale services
1). 18 months' warranty for all of our machines except of the pipes, valves, pumps etc.
2). 24 hours technical support by email, skype, mobile-phone.
3). Calling or door-to-door service.
4). Engineers are available to overseas for technical support or producing guidance.
5). Original manufacturers' price for quick-wear parts of our machines.
Payment Terms:
1. Only accept these terms: FOB / CIF / CFR
2. T/T or L/C
3. 40% deposite in advance by T/T, 60% T/T after the products are inspected by buyers before delivery.
1. Wooden case packing if necessery.
2. Very big machines packed by plastic bags.
3. We can supply shipper, or buyer can assign the shippers.
Dafeng - your best choice
- your trustful partner in China.
